Rated frequency(Hz) |
50 60 |
Rated voltage(V) |
400/230 400/230 |
Rated current(A) |
10.87 12.3 |
Rated output power(kW) |
6 6.8 |
Max rotation speed(rpm) |
6.6 7.48 |
Rated rotation speed(rpm) |
3000 3600 |
Power factor(cos) |
0.8(lag) |
Phase number |
three phase |
Noise level[dB(A)@7m] |
70~75 |
Overall dimension(L*W*H)[mm(in)] |
850*520*740 |
Dry weight[kg(ibs. )] |
185 |
Engine model |
12DL-500 |
Engine type |
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine |
Displacement[ml(cu. in)] |
505 |
Bore*stroke[mm(in)] |
87*85 |
Rated power[kW(Hp)/rpm] |
7.4(10)/3000, 8.1(12)/3600 |
Total consumption at full load[g(ml)/kw. h] |
275(327)/3000 280(333)/3600 |
Cooling system |
Forced air-cooled |
Fuel |
0# (summer), -10# (winter) light diesel oil |
Lube |
SAE10W30(above CC grade) |
|
|
Excitation mode |
Self-excitation and constant voltage(AVR) |
