Rated frequency(Hz) |
50 60 |
Rated voltage(V) |
400/230 400/230 |
Rated current(A) |
6.1 7.2 |
Rated output power(kW) |
4.2 5.0 |
Rated rotation speed(rpm) |
3000 3600 |
DC output |
No |
Power factor(cos) |
0.8(Applied to KVA) |
Phase number |
Three phase |
Noise level[dB(A)@7m] |
72~77 |
Overall dimension(L*W*H)[mm(in)] |
720x492x650(28.35x19.37x25.59) |
Dry weight[kg(ibs. )] |
100(220) |
Structure type |
Open-frame type |
Coupling mode |
Transmission shaft rigid coupling |
Engine model |
KM186F/FE |
Engine type |
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine |
Displacement[ml(cu. in)] |
406(24.78) |
Compression ratio |
19: 1 |
Rated power[kW(Hp)/rpm] |
5.7(7.75)/3000, 6.3(8.57)/3600 |
Starting system |
X: Recoil starter E: electric starter |
Rotation direction(View from flywheel) |
Clockwise |
Fuel |
0# (summer), -10# (winter) light diesel oil |
Lube |
SAE10W30(above CC grade) |
Low oil pressure alert system |
With |
Excitation mode |
Self-excitation and constant voltage(AVR) |
