Rated frequency(Hz)
|
|
50 60
|
Rated voltage(V)
|
|
230 230/115
|
Rated current(A)
|
|
7.4 8.7/17.4
|
Rated output power(kW)
|
|
1.7 2.0
|
Rated rotation speed(rpm)
|
|
3000 3600
|
DC output
|
|
12V 8.3A
|
Power factor(cos)
|
|
1.0
|
Phase number
|
|
Single phase
|
Noise level[dB(A)@7m]
|
|
72~77
|
Overall dimension(L*W*H)[mm(in)]
|
|
575×400×530 (22.64×15.75×20.87)
|
Dry weight[kg(ibs.)]
|
|
60(132)
|
Structure type
|
|
Open-frame type
|
Coupling mode
|
|
Transmission shaft rigid coupling
|
Engine model
|
|
KM170F
|
Engine type
|
|
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine
|
Displacement[ml(cu.in)]
|
|
211(12.88)
|
Compression ratio
|
|
20:1
|
Rated power[kW(Hp)/rpm]
|
|
22.5(3.4)/3000,2.8(3.8)/3600
|
Starting system
|
|
Recoil
|
Rotation direction(View from flywheel)
|
|
Clockwise
|
Fuel
|
|
0# (summer),-10# (winter) light diesel oil
|
