Content |
Specifications |
Basic |
CPU & Chipset |
Intel®Celeron® J1800 Dual Core(2.58 GHz 1M Cache)
Intel®Celeron® J1900 Quad Core (2.0GHz, 2M Cache)
System on chip (SoC) |
Memory |
2GB DDR3 1333MHz, SoDIMM (Up to 8GB) |
Storage |
2.5", SATA-III SSD 64GB↑
Support IDE/ACHI mode |
Display |
15", 1024 X 768, 24Bit, Luminance : 300 cd/㎡, Backlight : LED |
Dual Display port |
1EA HDMI, Intel® HD Graphics |
LAN |
1EA (Realtek RTL8111F PCIe GbE Controller) |
Serial |
5EA (DSUB-9p x 2EA / RJ-45 x 3EA)
Support Powered COM1,2 (select by BIOS) |
Parallel(LPT) |
- |
PS/2 |
- |
USB |
4EA(I/O)(USB3.0&2.0), 2EA (Rear) (USB 2.0) |
Audio |
Line-Out |
Speaker |
1 EA (1W) (Internal Speaker) |
Cooler & FAN |
Fanless |
Power Adaptor |
60[W] Adaptor, Input AC 100~240V/50~60HZ, DC 12V/5A |
Dimension(mm) |
384(W) x 347(H) x 225(D) (Normal Angle, With Stand) |
Weight |
4.8kg |
OS supported |
POSReady7 / Windows 10 IoT / Linux / Android |
Optional |
OS |
POSReady7 / Windows 10 IoT |
Storage |
2.5", SATA-III HDD 500 |
Touch Panel |
15"Bezel type, 5-Wire Resistive
15”Bezelless type, Projective Capacitive Touch |
Dual Display |
9.7", TFT-LCD, 1024x768, LED panel (Touch) |
Customer Display |
VFD type, 20 Characters X 2 Lines, Serial(RS-232C) |
Secure Card Reader |
EMV1, EMV2, MSR ISO Track1/2/3 |
Wall Mount |
Fixed Type / Swivel Type (75x75, 100x100mm VESA) |
Case Color |
White & Black (Bezel type only)
Black
Black & White (Bezelless type only) |
