Model
|
RT-662C
|
RT-665C
|
| Processor |
Intel® Atom™ N270, 512K L2 Cache, 1.6Ghz, 533Mhz FSB
|
| System Memory |
1GB Standard, Maximum 4 GB (2 x 200-pin DDR2)
|
| Power Supply |
90W (12V / 7.5A) External Power Adaptor
|
| Storage Device |
1 x 2.5" SATA HDD or 1 x 2.5" SSD (Optional) or 1 x SATA DOM (Optional)
|
| Graphics |
---
|
| Speaker |
Built-in Speaker 2W x 2
|
| Construction |
Aluminum Die-casting
|
| Housing Color |
Black / Silver
|
| Touch LCD Display |
| Size / Resolution |
12" TFT LCD / 800 x 600
|
15" TFT LCD / 1024 x 768
|
| Brightness |
400 (CCFL) cd/m²
|
250 / 350 (CCFL) cd/m²
|
| Touch Screen |
5-Wire Resistive Touch
|
| |
| I/O Ports |
| Serial Port |
5 x External : COM1, COM2, COM5, COM6 (DB9), COM4 (RJ45 with LED)
|
| USB Port |
4 x External
|
| Printer Port |
1 x Bi-directional Parallel port
|
| Cash Drawer Port |
1 x 12V RJ11 (Single / Dual)
|
| LAN Port |
1 x RJ45 Giga LAN
|
| Keyboard / Mouse |
---
|
| Video Port |
1 x VGA
|
| Audio Port |
1 x Line-out
|
| DC Output |
1 x 12V DC Jack 2.5 mm
|
| |
| OS Supported |
| Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
| Linux |
Per Request
|
| |
| Physical Dimensions |
| Dimensions (WxHxD) |
320 x 345 x 271 mm
|
370 x 389 x 271 mm
|
| |
| Environment |
| EMI / Safety |
CE, FCC Class A
|
| Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
| Storage Temperature |
-10˚C ~ 50˚C (14˚F ~ 122˚F)
|
| Relative Humidity |
10% ~ 90% (Non-condensing)
|
| |
| Optional Peripherals |
| Magnetic Stripe Card Reader |
MCR Single/Dual/Triple Track
|
| 2-in-1 / 3-in-1 Module |
MCR + i-Button / MCR + RFID / MCR + Fingerprint / MCR + Smartcard + i-Button
|
| 2nd Display |
12.1"/ 15" Pole-type LCD Display (Touch Screen Optional)
|
| Customer Display |
VFD / LCM Pole-type Customer Display
|
