Model
|
RT-662D
|
RT-665D
|
Processor
|
Intel® Atom™ D525 1M L2 Cache 1.8Ghz
|
System Memory
|
1 GB Standard, Maximum 4 GB (1 x 204-pin DDR3)
|
Power Supply
|
90W (12V / 7.5A) External Power Adaptor
|
Storage Device
|
1 x 2.5" SATA HDD
|
1 x 2.5" SATA HDD (Swappable)
|
Graphics
|
Intel® GMA 3150
|
Speaker
|
Internal Speaker 2W x 2
|
Construction
|
Aluminum Die-casting
|
Housing Color
|
Leather Black / Piano White
|
Touch LCD Display
|
Size / Resolution
|
12" TFT LCD / 800 x 600
|
15" TFT LCD / 1024 x 768
|
Brightness(Backlight Type)
|
330 cd/m² (LED)
|
250 (CCFL) / 450 cd/m² (LED)
|
Touch Screen
|
5-Wire Resistive Touch
|
I/O Ports
|
Serial
Port
|
2 x Internal : COM3 (Touch), COM6 (Reserved)
|
4 x External : COM2 (DB9) COM1, COM4, COM5 (RJ45)
|
USB
Port
|
5 x Internal, 4 x External
|
Printer
Port
|
1 x Bi-directional Parallel port
|
Cash
Drawer Port
|
1 x RJ11(12V)
|
LAN
Port
|
1 x RJ45 Giga LAN
|
PCI Slot
|
1 x Mini PCI-e(Internal)
|
Keyboard / Mouse
|
1 x PS/2 Port
|
Video
Port
|
1 x VGA
|
Audio
Port
|
1 x Line-out, 1 x Mic-in
|
DC Output
|
1 x 12V DC Jack 2.5 mm
|
OS Supported
|
Windows
|
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
Linux
|
Per Request
|
Physical Dimensions
|
Dimensions (WxHxD)
|
320 x 345 x 271 mm
|
370 x 389 x 271 mm
|
Environment
|
EMI / Safety
|
CE, FCC Class A
|
Operating Temperature
|
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
Storage Temperature
|
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
Relative Humidity
|
10% ~ 90% (Non-condensing)
|
Optional
Peripherals
|
Magnetic Stripe Card Reader
|
Integrated MCR Module (Single / Dual / Triple Track
Selectable)
|
2-in-1 / 3-in-1 Module
|
Integrated MCR + i-Button / MCR + RFID / MCR + Fingerprint
/ MCR + Smartcard + i-Button
|
2nd Display
|
Integrated 12.1"/ 15" Pole-type LCD Display
(Touch Screen Optional)
|
Customer Display
|
VFD / LCM Pole-type Customer Display
|
Wireless LAN
|
Integrated 802.11 b/g/n Wireless Module
|
2nd Storage
|
SATA DOM
|
