Model
|
AP-3435
|
| Processor |
Intel® Atom™ D525, 1M L2 Cache 1.8Ghz
|
| System Memory |
1GB Standard, Maximum 4GB (1x204-pin DDR3)
|
| Power Supply |
90W (12V / 12.5A) External Power Supply
|
| Storage Device |
1 x 2.5" SATA HDD
|
| Graphics |
Intel® GMA 3150
|
| Speaker |
Internal Speaker 2W x 2
|
| Construction |
Aluminum Die-casting + Plastic + Glass
|
| Housing Color |
Black with Silver Trim
|
| Touch LCD Display |
| Size / Resolution |
15" TFT-LCD/ 1024 X 768
|
Brightness
(Backlight Type) |
250 cd/m²(CCFL) with Tempered Glass / 350 cd/m²(LED)
|
| Touch Screen |
5-Wire Resistive Touch / Projected Capacitive Touch
|
| |
| I/O Ports |
| Serial Port |
3 x External: COM1, COM2 (DB9), COM4 (RJ-45)
USB Port
|
| USB Port |
5 x External (4 Rear + 1 Side)
|
| Cash Drawer Port |
1 x RJ11 (12V)
|
| Printer Port |
1 x Bi-directional Parallel port
|
| Keyboard / Mouse |
1 x PS/2
|
| LAN Port |
1 x RJ45 Giga LAN
|
| PCI Slot |
1 x Mini PCI-e (Internal)
|
| Audio Port |
1 x Line Out
|
| VGA Port 1 x VGA |
1 x VGA
|
| DC Output |
1 x 12V DC Jack 2.5 mm
|
| |
| OS Supported |
| Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
| Linux |
Per Request
|
| |
| Physical Dimensions |
| Dimensions (WxHxD) |
367 x 294 x 223 mm
|
| |
| Environment |
| EMI / Safety |
CE, FCC Class A
|
| Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
| Storage Temperature |
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
| Relative Humidity |
10% ~ 90% (Non-condensing)
|
| |
| Optional Peripherals |
| Magnetic Stripe Card Reader |
Integrated MCR Module (Single / Dual / Triple Track Selectable)
2nd Display
|
| 2nd Display |
Integrated 15" Pole-type LCD Display (Touch Screen Optional)
|
| Customer Display |
Integrated LCM Customer Display / Pole Type VFD Display
Wireless LAN
|
| Wireless LAN |
Integrated 802.11 b/g/n Wireless Module
|
| Identification Devices |
RFID 13.56 MHz / Fingerprint Reader / i-Button
|
