Model
|
MP-3432
|
MP-3435
|
| Processor |
Intel® Atom™ D525, 1M L2 Cache, 1.8Ghz
|
| System Memory |
1 GB Standard, Maximum 4 GB (1 x 204 pins DDR3)
|
| Power Supply |
90W (12V/7.5A) External Power Adaptor
|
| Storage Device |
1 x 2.5” SATA HDD or SATA SSD
|
| Speaker |
Internal Speaker 2W x 2
|
| Construction |
ABS + SECC
|
| Housing Color |
Charcoal + Silver
|
| Touch LCD Display |
| Size / Resolution |
12" TFT / 800 x 600
|
15" TFT LCD / 1024 x 768
|
| Brightness (Backlight Type) |
330 cd/m² (LED)
|
250 cd/m²(CCFL)
|
| Touch Screen |
5-Wire Resistive Touch
|
| I/O Ports |
| Serial Port |
3 x Internal: COM3 (Touch), COM5 (LCM), COM6 (Reserved)
|
|
3 x External : COM1, COM2 (DB9), COM4 (RJ45)
|
| USB Port |
4 x Internal (1 MSR, 3 Reserved), 5 x External (4 Rear, 1 Front)
|
| Printer Port |
1 x Bi-directional Parallel Por
|
| Cash Drawer Port |
1 x RJ11 (12V)
|
| Keyboard / Mouse |
1 x PS/2
|
| LAN Port |
1 x RJ45 Giga LAN
|
| PCI Slot |
1 x Mini PCI-e (Internal)
|
| Video Port |
1 x VGA
|
| Audio Port |
1 x Line-out, 1 x Mic-in
|
| DC Output |
1 x 12V DC Jack 2.5 mm
|
| OS Supported |
| Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
| Linux |
Unbuntu 8.04 LTS
|
| Physical Dimensions |
| Dimensions (WxHxD) |
326 x 356 x 388 mm
|
382 x 356 x 388 mm
|
| Environment |
| EMI / Safety |
CE, FCC Class A
|
| Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
| Storage Temperature |
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
| Relative Humidity |
10% ~ 90% (non-condensing)
|
| Optional Peripherals |
| Magnetic Stripe Card Reader |
Integrated MCR Module (Single / Dual / Triple Track Selectable)
|
| 2-in-1 / 3-in-1 Module |
Integrated MCR + i-Button / MCR + RFID / MCR + Fingerprint / MCR + Smartcard + i-Button
|
| 2nd Display |
Integrated 12.1" / 15" Pole-type LCD Display (Touch Screen Optional)
|
| Customer Display |
Integrated in LCM or VFD / LCM Pole-type Customer Display
|
| Wireless LAN |
Integrated 802.11 b/g/n Wireless Module
|
| 2nd Storage Device |
SATA DOM
|
