| CPU |
VIA C7 1.5GHz |
| Memory |
2 memory slots, Max. 2GB ; DDR2 DIMM type |
| Operator Display |
15" TFT Touch (1024 x 768) |
12.1" TFT Touch (800 x 600) |
| Customer display |
2 Lines x 20 Characters 12.1"Model |
| 15" or 12.1" TFT with Dual display option (*Refresh model) |
| HDD |
160 GB or over, SATA x 1 |
| Options |
Card reader (MSR); iButton; remote, fixed, or tilting LIU display; cover and cable for wireless interface adapter (USB); Solid State Flash Disk (Max. 4GB) |
| Interfaces |
2 x COM D-Sub9 (male); 2 x powered COM D-Sub9 (female) |
| 6 x USB (2.0); 1 x powered USB (12V, *Reflesh model); 1 x powered USB (24V) |
| 1 x PS/2 for mouse & 1 x for keyboard |
| 2 x 24V drawer interface |
| 1 x 15 pin VGA female type |
| LAN 10 Base-T/100 Base-TX Ethernet (RJ-45) with LED |
| Audio |
Line-out / Mic-in |
| AC Inlet |
AC inlet connector |
| Power Supply |
95W / 105W internal switching |
| Weight |
11.5 kg / 25.35 lbs |
10.5 kg / 23.15 lbs |
| Dimensions |
366 (W) x 251 (D) x 359 (H) mm |
306 (W) x 247 (D) x 337 (H) mm |
| 14.4 (W) x 9.9 (D) x 14.2 (H) inch |
12.1 (W) x 9.7 (D) x 13.35 (H) inch |
