LCD
|
15“ TFT LCD
|
|
CPU
|
AMD Geode™ LX 800 (500MHz)
|
|
Chipset
|
AMD Geode™ LX 800+ AMD Geode™ CS5536
|
|
I/O Interface
|
|
USB
|
2 x USB 2.0
|
|
Serial/COM
|
2 x RS-232 COM Port (pin 9 with RI , 5V or 12V switch selectable)
With LED Indicator (12VRed / 5VYellow / RIGreen)
|
|
LAN (10/100Mbps)
|
1 x RJ-45
|
|
Cash Drawer Port
|
1 x RJ-12 (12V) for Cash Drawer
|
|
DC Jack
|
1 x DC Jack
1 x Power Switch
1 x Reset Button
|
|
POWER LED
|
1
|
|
|
Memory
|
Supports one 1GB (maximum)333MHz or 400MHz SO-DIMM
|
|
Max Resolution
|
1024 x 768
|
|
Brightness (cd/m²)
|
350
|
|
Contrast Ratio
|
700:1
|
|
LCD Color
|
262K
|
|
Touch Screen Type
|
Resistive Type 5-Wire
|
|
Pixel Pitch (mm)
|
0.297(H) x 0.297(V)
|
|
Viewing Angle (H-V)
|
140(H) / 125(V)
|
|
Backlight MTBF
|
50000 hrs
|
|
Housing Material
|
ABS + PC Plastic front frame
|
|
IP Level
|
IP 64 in front
|
|
Front Panel Color
|
Silver
|
|
HDD
|
1 x 2.5" HDD bay With ANTI-SHOCK
|
|
SSD
|
CF Type II
|
|
Mini-PCI Slot
|
1x mini-PCI slot (for build-in wireless 802.11 b/g module)
|
|
Built-in Speaker
|
AMP 1.5W+AMP 1.5W
|
|
Power Adapter
|
P/N No.: 63000-FSP0601AD101C-RS
Power: 60W
Input: 90VAC~264VAC @ 50/60Hz
Output:12VDC
|
|
Power Consumption
|
38W
|
|
MSR
|
Magnetic Card Reader (USB interface) (optional)
|
|
MSI
|
Magnetic Card, Smart Card,Dallas iButton (USB interface) (optional)
|
|
Cash Drawer
|
RJ-12 (12VDC) interface (optional)
|
|
Bar Code Reader
|
Hand-held Laser Scanner (USB interface) (optional)
|
|
EMC and Safety
|
CE,FCC,CCC,CB
|
|
Operating Temperature
|
0°C~50°C
|
|
Storage Temperature
|
-20°C~60°C
|
|
Dimension (WxHxD) (mm)
|
394 x 309 x 61
|
|
Mounting
|
Panel, Wall, Stand VESA 100 x 100mm
|
|
Net Weight
|
3.2 Kg
|
|
OS Support
|
Windows XPE, Windows CE 5.0 or Windows CE 6.0 (optional)
|
|
Watchdog Timer
|
Software programmable supports 1~255 sec. System reset
|
