Model
|
RP-3112B
|
RP-3115B
|
| Processor |
VIA Eden™ (ULV) Processor 1.6 GHz
|
| System Memory |
1 GB Standard, Maximum 1 GB (1 x 200-pin DDR2)
|
| Power Supply |
150W (12V/12.5A) External Power Adaptor
|
| Storage Device |
1 x 2.5” SATA HDD
|
|
1 x CF Card (Optional)
|
| Construction |
Aluminum Die-casting, Plexi-Glass Acrylic (Front Bezel)
|
| Housing Color |
Black / Silver
|
| Touch LCD Display |
| Size / Resolution |
12” TFT LCD / 800 x 600
|
15” TFT LCD / 1024 x 768
|
| Brightness |
400 cd/m²
|
250 / 350 cd/m²
|
| Touch Screen |
5-Wire Resistive Touch
|
| |
| I/O Ports |
| Serial Port |
3 x External : COM1 & COM2, COM4 (RJ45)
|
| USB Port |
4 x External (2 in Front, 2 in Rear)
|
| Printer Port |
1 x Bi-directional Parallel Port
|
| Cash Drawer Port |
1 x 12V RJ11 (Single/Dual)
|
| Keyboard / Mouse |
1 x PS/2
|
| LAN Port |
1 x RJ45 10/100
|
| Video Port |
1 x VGA
|
| Audio Port |
1 x Line-out
|
| DC Output |
1 x 12V for 2nd Display
|
| |
| OS Supported |
| Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
| Linux |
Per Request
|
| |
| Physical Dimensions |
| Dimensions (WxHxD) |
325 x 345 x 235 mm
|
375 x 390 x 235 mm
|
| |
| Environment |
| EMI / Safety |
CE, FCC Class A
|
| Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
| Storage Temperature |
-10˚C ~ 50˚C (14˚F ~ 122˚F)
|
| Relative Humidity |
10% ~ 90% (non-condensing)
|
| |
| Optional Peripherals |
| Magnetic Stripe Card Reader |
MCR Single/Dual/Triple Track
|
| 2-in-1 / 3-in-1 Module |
MCR+i-Button/MCR+RFID/MCR+Fingerprint/MCR+Smartcard+i-Button
|
| 2nd Display |
8.4”/12.1”/15” Pole-type LCD Display (Touch Screen Optional)
|
| Customer Display |
VFD / LCM Pole-type Customer Display
|
| Wireless LAN |
Integrated 802.11 b/g/n Wireless Module
|
