Model
|
MP-2410
|
| Processor |
Intel® Atom™ N270, 512K L2 Cache, 1.6Ghz, 533Mhz FSB
|
| System Memory |
1 GB Standard, Maximum 2 GB (1 x 200-pin DDR2)
|
| Power Supply |
120W (24V / 5A) ; 180W (24V / 7.5A) External Power Adaptor
|
| Storage Device |
1 x 2.5" SATA HDD Swappable
|
| 2nd Storage Device |
1 x CF II
|
| Speaker |
Internal Speaker 2W x 2
|
| Construction |
Aluminum Die-casting + Plastic
|
| Housing Color |
Black + White (Standard) / Black
|
| Touch LCD Display |
| Size / Resolution |
10.4” LED LCD 800 x 600
|
10.4” LED LCD 800 x 600
|
10.4” TFT 1024 x 768
|
| Brightness (Backlight Type) |
250 cd/m² (LED)
|
400 cd/m² (LED)
|
350 cd/m² (LED)
|
| Input Interface |
TTL
|
LVDS
|
LVDS
|
| Touch Screen |
5-Wire Resistive Touch
|
| I/O Ports |
| Serial Port |
3 x Internal: COM5 (Printer), COM3 (LCM), COM6 (Reserved)
|
|
3 x External: COM1, COM2, COM4 (DB9)
|
| USB Port |
6 x Internal (1 Touch, 1 LCM, 1 MSR, 3 Reserved), 4 x External (2 Rear, 2 Hidden)
|
| Cash Drawer Port |
1 x RJ11 (12V / 24V)
|
| Keyboard / Mouse |
1 x PS/2
|
| LAN Port |
1 x RJ45 Giga LAN
|
| Video Port |
1 x VGA
|
| Audio Port |
1 x Line-out
|
| DC Output |
1 x 12V DC Jack 2.5 mm
|
| OS Supported |
| Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
| Linux |
Per Request
|
| Physical Dimensions |
| Dimensions (WxHxD) |
260 x 289 x 185 mm (Display Folded); 260 x 289 x 343 mm (Display Up)
|
| Weight |
| Weight of Console |
Net 9kg, Gross 10kg
|
| Environment |
| EMI / Safety |
CE, FCC Class A
|
| Operating Temperature |
0°C ~ 40°C (32°F ~ 104°F)
|
| Storage Temperature |
-10°C ~ 55°C (14°F ~ 131°F)
|
| Relative Humidity |
10% ~ 90% (Non-condensing)
|
| Built-in Printer |
| Printer Method |
Thermal Line Printing
|
| Printing Width |
58 mm / 80 mm /82.5 mm
|
| Paper Size |
Paper Roll: 80 / 82.5 (W) mm x 100 mm Diameter
|
| Printing Speed |
Max 230 mm/s
|
| Interface |
RS232
|
| Optional Peripherals |
| Magnetic Stripe Card Reader |
Integrated MCR Module (Single / Dual / Triple Track Selectable)
|
| IC Card Reader |
Integrated Available
|
| LCM |
Integrated LCM Module (192 x 32 Graphic/ 20 x 2 Characters)
|
| Wireless Module |
CDMA / GSM / Wi-Fi Module
|
