CPU
|
Intel Celeron M440 (1.86GHz), Intel Core2 Duo T7400
(2.16GHz)
|
Chipset
|
945GME
|
Memory
|
512MB DDR2 SODIMM (Max. 4GB)
|
HDD
|
2.5" HDD 250GB/ 160GB or over SATA I/F (Max. 2
Drives)
|
RAID
|
RAID1 (Mirroring) Support
|
CD/DVD Drive
|
Integrated (Option)
|
U-SSD I/F
|
Yes
|
Floppy Disk Drive
|
External drive USB I/F (option)
|
Display I/F
|
VGA (Analog) (LVDS Digital : Option)
|
LAN
|
10 Base-T/100 Base-TX/1000 Base-T
|
Audio
|
Line-out x 2 (Front & Rear), Mic-in x 1 (Rear)
|
Speaker
|
Beep, Sound (Option)
|
PS/2
|
Keyboard x 1, Mouse x 1 (Rear)
|
RS232C
|
4 + 2 (Option)
|
Normal USB
|
3 (1: Front, 2: Rear)
|
Powered USB
|
12V x 5 (Rear), 24V x 1 (Rear)
|
Drawer Port
|
2 (Toshiba I/F)
|
Parallel
|
1 (Rear)
|
PCI Slot
|
2
|
Front LED
|
Disk, Power, Diagnostics
|
AC Outlet
|
1
|
Cabinet Colour
|
FW2 (Fair White2), CB (Cool Black)
|
Weight
|
8.8 kg / 19.4 lbs
8.9 kg / 19.62 lbs (Dual Disk Model)
|
Dimensions
|
315(W) x 466(D) x 112.5(H) mm (with cable cover)
12.4"(W) x 18.34"(D) x 4.42"(H) (with cable cover)
315(W) x 396(D) x 112.5(H) mm (without cable cover)
12.4"(W) x 15.59"(D) x 4.42"(H) (without cable cover)
|
