Model |
CT-S281 (For Europe/Asia) |
CT-S281 (For the Americas) |
Printing method |
Line thermal dot printing |
Printing width |
48mm / 384 dots/line |
Dot pitch |
8 × 8 dots/mm (203 dpi) |
Printing speed |
Max. 80mm/sec (fastest, print density 100%), 640 dot-lines/sec. |
Number of print
columns and characters |
Font
|
Maximum number
of characters
|
Character size
|
Dot configuration |
Font A |
32 columns |
1.50 × 3.00mm |
12 × 24 dots |
Font B |
42 columns |
1.13 × 3.00mm |
9 × 24 dots |
Font C |
48 columns |
1.00 × 3.00mm |
8 × 16 dots |
|
Character type |
Alphanumeric, International, PC437/850/852/857/858/860/ 863/864/865/866, WPC1252, Katakana, Thai Code 18 |
User memory |
256 KB (capable of storing user-defined characters and logos) |
Barcode type |
UPC-A/E, JAN (EAN) 13/8 columns, ITF, CODE39, CODE128, CODEBAR, CODE93, PDF417, QR Code |
Line spacing |
4.23mm (1/6 inch) (changeable using commands) |
Paper roll |
Paper roll: 58mm × ,max.Φ83mm
Label paper roll: 58mm × max.Φ83mm
Paper thickness: 60 to 100µm |
Interface |
Serial (RS-232C compliant), USB |
Buffer size |
4K bytes/45 bytes |
Supply voltage |
DC8.5V&plusminus;5% |
Power consumption |
Approx. 18W (normal printing), 2W (standby) |
AC adapter |
Rate input: AC100 to 240V, 50/60Hz, 150VA
Rate output:DC8.5V, 2.5A |
Weight (approx) |
Printer:Approx.630g
AC adapter:Approx.240g |
Outside dimensions |
106 (W) × 180 (D) × 105 (H) mm |
Operating temperature
and humidity |
5 to 40°C, 10 to 85% RH (no condensation) |
Storage temperature
and humidity |
-20 to 60°C, 10 to 90% RH (no condensation) |
Reliability *1 |
Printer head life: 50km, 100 million pulses
Auto cutter: 1 million cuts |
Safety standard *2
standards |
TÜV, GS, CE marking |
UL, C-UL, FCC class B |
