| Printing method |
Thermal fixed head |
| Resolution |
203 dpi (8 dots/mm) / enhanced quality head |
| Printing speed |
High Quality >100 mm/sec, Normal >180 mm/sec, High Speed >220 mm/sec |
| Paper width |
from 60 to 82.5 mm |
| Roll dimension |
max 180mm (150mm with paper roll on upper position) |
| Print direction |
Straight, 90°, 180°, 270° |
| Type styles |
Normal, 1x to 8x height and width, reverse, underscored, italic, bold |
| Characters set |
PC437, PC850, PC860, PC863, PC865, PC858 |
| Emulation |
CUSTOM/POS |
| Interfaces |
RS232 / USB / Ethernet |
| Data buffer |
16 KB |
| Flash memory |
384 KB |
| Graphics memory |
2 logos of 608 x 862 dots (for 80/82.5mm paper width) |
| Drivers |
Full Driver for win 2K, XP, Vista, 7; Linux driver |
| Software tools |
Font Editor; Logo Editor; Status Monitor |
| Power supply |
24 Vdc±10% |
| Power consumption* |
2.2 A |
| MTBF** |
590.000 hours |
| Head life |
100Km / 100M pulses |
| MCBF |
1.500.000 cutter life |
| Dimensions (mm) |
120x121x140 |
| Weight |
1.9 Kg |
|
