Series |
TSP100 |
Model Name |
TSP143PU-24 |
TSP143U |
TSP143LAN |
TSP143GT |
Printer Case Colour |
Star White / Charcoal Grey (*1) |
Ice White / Piano Black |
Installation |
Horizontal use / Vertical use (with Wall Mount Blacket / Rubber foot) |
Printer Method |
Direct Thermal Line Printing |
Character
Specifications |
Print Configuration |
Alphanumeric Characters: 12 x 24 dots : 9 x 24 dots,
Chinese Characters 12 x 24 dots, 24 x 24 dots |
No. of Columns |
Maximum 48 columns (12 x 24 fonts) / 24 column (24 x 24 fonts) |
Character Size |
ANK : 12 x 24 fonts 1.5 x 3.0 mm (W x H), 9 x 24 fonts(*3) 1.125 x 3.0 mm (W x H)
Chinese Characters : 12 x 24 fonts 1.5 x 3.0 mm (W x H), 24 x 24 fonts 3.0 x 3.0 mm (W x H) |
Character Type |
Alphanumeric Characters, Extended Graphics, International Characters, JIS First Standard Chinese Characters, JIS Second Standard Chinese Characters |
Barcodes |
UPC-A/E, JAN/EAN-8/13, ITF
CODE39, CODE93, CODE128, CODABAR(NW-7)and QR |
Print Resolution |
8 dots per mm (203dpi x 230dpi) |
Emulation |
Star Mode, ESC/POS mode (Page mode is not supported) |
Interfaces |
USB 2.0 |
Ethernet |
USB 2.0 |
Full Speed(*4) |
(100BASE-TX/10BASE-T) |
Full Speed(*4) |
Print Speed |
up to 125 mm/second |
up to 250 mm/second |
Paper
Specifications |
Media Types |
Thermal Paper Roll |
size |
80 mm (default), 58 mm (with paper guide fitted to the specified position) |
Roll Diameter |
Max. 83 mm |
Thickness |
0.065 - 0.085mm |
Auto-Cutter |
Cutting Method |
Guillotine |
Cutting Modes |
Partial cut |
Life |
up to 1 million cuts (with recommended paper) |
Power Supply Voltage |
DC24V ±10% |
AC 100V ±10% (Internal P/S) |
Power
Consumption |
During ASCII Continuous Printing |
Approx. 40W |
Approx. 42W |
Print Ready Mode |
- |
- |
Peripheral Drive Circuit |
2 circuits (24V max. 1A), 1 compulsion input |
Reliability (MCBF) |
60 million lines |
Dimensions |
142×204×132 mm (WxDxH) |
Weight |
1.53 kg
(without paper roll) |
1.75 kg (without paper roll) |
EMI Standards |
VCCI: Class A, FCC: Class A, EN55022: Class B, UL, TUV-GS (EN60950) |
AC adapter (Option) |
PS60A-24B(*5) |
No AC adapter required (Internal P/S) |
Recommended Connectors |
1.8 m USB cable
TSP1 (*5)
PUB cable 1×8LNL
1.2M (*6)- |
- |
Options |
Buzzer (BU01-24-A) (*5)
Splash Proof Cover (SPC-T100), Vertical Mount Kit (VS-T650) |
