MODEL NUMBER |
TM-H6000IV |
|
Receipt |
Slip |
Endorsement |
Print Station |
Thermal line printing |
9-pin serial impact dot matrix |
9-pin serial impact dot matrix |
Print Speed |
Up to 300mm/sec
(94 lps, {1/8"} conversion) |
Up to 5.7 lps
(40 columns, 17.8 cpi) |
Up to 4.0 lps |
Print Font |
9 x 17 / 12 x 24 |
5 x 9 / 7 x 9 |
5 x 7 |
Column Capacity |
56 / 42 columns |
60 / 45 columns |
40 columns |
Character Size (W x H) |
0.99mm x 2.4mm
1.41mm x 3.39mm |
1.56mm x 3.1mm
1.24mm x 3.1mm |
1.1mm x 2.42mm
NA |
Barcode |
One- and two-dimensional |
NA |
NA |
Paper Dimensions |
79.5mm ± 0.5mm x diameter 83.0mm |
68mm to 230mm x 68mm to 297mm (W x L) |
NA |
Paper Thickness |
0.06mm to 0.09mm |
0.09mm to 0.47mm |
0.09mm to 0.2mm |
Copy Capacity |
NA |
One original & 3 copies |
One original & 2 copies |
Inked Ribbon |
NA |
ERC-32B (Black) |
ERC-43B (Black) |
Ribbon Life |
NA |
4,000,000 characters |
3,000,000 characters |
Power Consumption |
Approx. 1.8 A (mean) |
1.7 A |
Approx. 1.7 A (mean) |
Reliability |
|
|
|
MTBF |
360,000 hours |
180,000 hours |
180,000 hours |
MCBF |
96,000,000 lines |
29,000,000 lines |
29,000,000 lines |
Device |
|
Character Set |
95 Alphanumeric, 37 International |
Interfaces |
Built-in USB, interface options including serial, parallel and ethernet |
Data Buffer |
45 bytes or 4 KB (up to 384 KB for 128 x 11 graphic fi les) |
Autocutter |
Scissors type with partial cut |
Supply Voltage |
24 VDC ±7% |
D.K.D. Function |
2 drivers |
Sensors |
Cover Open, Top of Form, Bottom of Form, Slip Eject, Roll Paper Near End, Roll Paper End |
Factory Options |
MICR Device, Endorsement Printer (E/P), Validation Printing Device, 58mm Paper Guide (PG-58II), Power Supply Unit (PS-180) |
Overall Dimensions (W x D x H) |
186mm x 278mm x 181mm (7.32" x 10.95" x 7.13") |
Weight |
Approx. 9.7lbs / 4.4kg |
Colour |
Epson Dark Grey, Epson Cool White |
Environmental Standards |
WEEE, RoHS Compliant |
OS Support |
Microsoft® Windows® 2008 / 2000 / XP / Vista / 7 / 8, WEPOS, POSReady |
Control Board |
|
EMC Standards |
VCCI Class A, FCC Class A, CE Marking, AS/NZS CISPR22 Class B |
Safety Standards |
UL / CSA / TUV (EN60950) / GOST-R (IEC60950. CISPR22) |
Dimensions and Weight |
