WiFi Power Pack Specifications
|
|
DK-USB Power Module
|
Designed for DC input 24V with 1A fuse and DC output with rated voltage of 5.0V and rated current of 500mA. Texture surface. USB is short-circuit.
|
|
Wireless Standards
|
IEEE 802. 11n,
IEEE 802. 11g,
IEEE 802. 11b
|
|
Dimensions (WxDxH)
|
2.2 x 2.2 x0.7 in. (57 x 57 x 18mm)
|
|
Antenna Type
|
On-Board
|
|
Frequency
|
2.4- 2.4835GHz
|
|
Single Rate
|
11n: Up to 150Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)
|
|
EIRP
|
<20dBm (EIRP)
|
|
Reception Sensitivity
|
135M: -70dBm@10%PER
65M: -73dBm@10%PER
54M: -76dBm@10%PER
|
|
Wireless Modes
|
AP Mode, Router Mode, Client Mode. Repeater Mode, Bridge Mode
|
|
Wireless Functions
|
Enable/ Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
|
|
Wireless Security
|
64/128/152-bit WEP,
WPA/ WPA2
WPA-PSK/ WPA2-PSK
|
|
WAN Type
|
Dynamic IP/ Static IP/ PPPoE/ PPTP/ L2TP
|
|
DHCP
|
Server. Client, DHCP Client
|
|
Quality of Service
|
WMM, Bandwidth Control |
|
Dynamic DNS
|
DynaDna, Comexe, NO-IP
|
|
Auto Power Down Mode
|
1-5 Minutes Configurable
|
|
VNP Pass-Through
|
PPTP, L2TP, IPSec (ESP Head)
|
|
Access Control
|
Local Management Control, Host List, Access Schedule, Rule management
|
|
Firewall Security
|
DoS, SPI Firewall
IP Address Filter/ MAC Address Filter/ Domain Filter
IP and MAC Address Binding
|
|
Management
|
Access Control
Local Management
Remote Manegment
|
