Model
|
RP-3212B
|
RP-3215B
|
Processor
|
Intel® Celeron® 440, 512K L2 Cache, 2.0Ghz, 800Mhz FSB
(HH80557RG041512)
Intel® Pentium® E5300, 2M L2 Cache, 2.6Ghz, 800Mhz FSB (AT80571PG0642ML)
|
System Memory
|
1 GB Standard, Maximum 4 GB (2 x 240-pin DDR2)
|
Power Supply
|
250W External Power Supply with 12V/24V Output
|
Storage Device
|
Supports 2 x 2.5 SATA HDD with RAID Function (0,1,10), 2nd
SATA HDD (Optional)
|
Speaker
|
Internal Speaker 2W x 2
|
Construction
|
Aluminum Die-casting, Plexi-Glass Acrylic (Front Bezel)
|
Housing Color
|
Black
|
Touch LCD Display
|
Size / Resolution
|
12.1" TFT LCD / 800 x 600
|
15" TFT LCD / 1024 x 768
|
Brightness
(Backlight Type)
|
400 cd/m² (CCFL)
|
250 / 350 cd/m² (CCFL)
|
Touch Screen
|
5-Wire Resistive Touch
|
I/O Ports
|
Serial
Port
|
3 x Internal : COM3 (Touch), COM4 (VFD / LCM or 2nd
Touch), COM6 (Reserved)
|
3 x External : COM1 & COM2 (DB9), COM5 (RJ45)
|
USB
Port
|
3 x Internal (1 WiFi, 1 MSR / 3-in-1, 1 Reserved), 5 x
External (1 Side, 4 Bottom)
|
Printer
Port
|
1 x Bi-directional
Parallel Port
|
Cash
Drawer Port
|
1 x RJ11 (12V)
|
Keyboard
|
1 x PS2
|
LAN
Port
|
1 x RJ45 Giga LAN
|
Video
Port
|
1 x VGA (DB15)
|
Audio
Port
|
1 x Line-out
|
OS Supported
|
Windows
|
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
Linux
|
Per Request
|
Physical Dimensions
|
Dimensions (WxHxD)
|
325 x 430 x 255 mm
|
375 x 430 x 255 mm
|
Environment
|
EMI / Safety
|
CE, FCC Class A
|
Operating Temperature
|
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
Storage Temperature
|
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
Relative Humidity
|
10% ~ 90% (Non-condensing)
|
Optional
Peripherals
|
Magnetic Stripe Card Reader
|
Integrated MCR Module (Single / Dual / Triple Track
Selectable)
|
2-in-1 / 3-in-1 Module
|
Integrated MCR + i-Button / MCR + RFID / MCR + Fingerprint
/ MCR + Smartcard + i-Button
|
2nd Display
|
Integrated 12.1” / 15” TFT LCD (Touch Screen Optional)
|
Customer Display
|
Integrated VFD / LCM Customer Pole-Display
|
Wireless LAN
|
Integrated 802.11 b/g/n Wireless Module
|
