Model
|
H-740
|
H-745B
|
Processor |
Intel® Celeron® 2.0Ghz, 128K L2 Cache, 400Mhz FSB
(RK80532RC041128)
|
Intel® Pentium® E5300, 2M L2 Cache, 2.6Ghz, 800Mhz FSB
(AT80571PG0642ML)
|
Intel® Pentium® 4 Processor 2.40 GHz, 512K Cache, 533
MHz FSB(RK80532PE056512)
|
System Memory |
256MB Standard, Maximum 1GB (1 x 184-pin DDR)
|
1GB Standard, Maximum 2GB (1 x 240-pin DDR2)
|
Power Supply |
250W External Power Supply
|
250W External Power Supply
|
Storage Device |
1 x 3.5" SATA HDD
|
1 x 2.5" SATA HDD
|
Speaker |
Internal Speaker 2W x 2
|
Internal Speaker 2W x 2
|
Construction |
Aluminum Die-casting
|
Housing Color |
Black / Silver
|
Touch LCD Display |
Size / Resolution |
12" TFT LCD / 800 x 600
|
15" TFT LCD / 1024 x 768
|
Brightness (Backlight Type) |
400 cd/m² (CCFL)
|
250 (CCFL) / 450 cd/m² (LED)
|
Touch Screen |
5-Wire Resistive Touch
|
|
I/O Ports |
Serial Port |
4 x External : COM1 & COM2 (DB9), COM4 COM (RJ45)
|
4 x External : COM3 (DB9), COM1, COM2, COM4 (RJ45)
|
USB Port |
2 x Internal, 4 x External
|
3 x Internal, 5 x External (4 Rear, 1 Side)
|
Printer Port |
1 x SCSI II Conector
|
1 x SCSI II Conector
|
Cash Drawer Port |
1 x RJ11 (12V)
|
1 x RJ11 (12V)
|
Keyboard / Mouse |
2 x PS/2
|
1 x PS/2 (KB Only)
|
LAN Port |
1 x RJ45 10/100
|
1 x RJ45 10/100
|
Video Port |
1 x VGA
|
1 x VGA
|
Audio Port |
1 x Line-out
|
1 x Line-out
|
DC Output |
1 x 12V DC Jack 2.5 mm
|
1 x 12V DC Jack 2.5 mm
|
|
OS Supported |
Windows |
Windows XP, Windows XPE, POSReady 2009
|
Windows XP, Windows XPE, POSReady 2009,
Windows 7
|
Linux |
Per Request
|
|
Physical Dimensions |
Dimensions (WxHxD) |
320 x 304 x 265 mm
|
370 x 350 x 265 mm
|
|
Environment |
EMI / Safety |
CE, FCC Class A
|
Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
Storage Temperature |
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
Relative Humidity |
10% ~ 90% (Non-condensing)
|
|
Optional Peripherals |
Magnetic Stripe Card Reader |
Integrated MCR Module (Single / Dual / Triple Track Selectable)
|
2-in-1 / 3-in-1 Module |
Integrated MCR + i-Button / MCR + RFID / MCR + Fingerprint / MCR + Smartcard + i-Button
|
2nd Display |
Integrated 12.1"/15" Pole-type LCD Display (Touch Screen Optional)
|
Customer Display |
VFD / LCM Pole-type Customer Display
|
Wireless LAN |
Integrated 802.11 b/g/n Wireless Module
|
2nd Storage Device |
CF II or IDE DOM
|
CF II or IDE DOM
|
