Item
|
PT-8850-182
|
PT-8850-201
|
PT-8850-215
|
CPU Type
|
Intel Core™2 Duo Processor E6400 @ 2.13GHz,
FSB 1066MHz, L2 cache 2MB, TDP 65W
|
Intel Pentium Dual-core Processor E2160 @
1.80GHz, FSB 800MHz, L2 cache 1MB, TDP 65W
|
Intel Celeron Processor 440 @ 2.0GHz, FSB
800MHz, L2 cache 512KB, TDP 35W
|
LCD
|
15"Active TFT color LCD, resolution 1024
x 768
|
Touch
|
5-wire Resistive touch (RS-232 interface)
|
Memory
|
1GB (up to 4 GB)
|
Ethernet
|
10/100M/1G
|
Storage
|
Internal 3.5¡¨ type SATA HDD 80GB x 2
|
I/O Interface
|
6 * COM ports (COM1~4 at back I/O, COM5~6 on
M/B) (COM1~4 provides DC +5V/12V with BIOS setting)
|
1 * DB-15 VGA port
|
1 * DB-25 for LPT port
|
1 * RJ11 port for 2 cash drawer(+24V)
|
1 * PS2 Keyboard port
|
1 * PS2 Mouse port
|
1 * RJ-45 LAN port with activity and link LEDs
|
2 * Audio ports (1 * Line-out , 1 * MIC-in)
|
6 * USB 2.0 (2 in the front; 2 in the back; 2
on the M/B)
|
Expansion Options
|
1 x PCI-E Slot
|
1 * Mini PCI-e
|
Optional Peripherals
|
3 tracks magnetic reader
|
Customer display module (2 x 20 VFD)
|
802.11 b/g Mini PCI Module support WiFi
function
|
Biometric Reader, Smart Card Reader, I-Button,
RFID reader
|
KB-32 32-keys keypad
|
2nd monitor(Dual screen)
|
Operation System
|
Windows Vista, XP, XP embedded, Linux (Fedora)
, WEPOS, POSReady
|
Power Supply
|
AC100~240V/DC19V, 4.75A, 90 watt power adaptor
(3P), 24V-tolerant
|
Dimensions
|
Physical:344mm (W) x348mm (D) x 375mm (H)
|
Operating Temperature
|
0~+40˚C
|
Storage Temperature
|
-20˚C~+60˚C
|
Operating & Storage Humidity
|
10%~80%
|
Certification
|
CE/FCC Class A, UL, cUL, CB, VCCI, BSMI
|
