15" Model
|
12.1"Model
|
CPU
|
Intel Celeron M 440 (1.86GHz)/ Intel Core2 Duo T7400
(2.16GHz)
|
Memory
|
512MB/ 1GB (Max. 4GB) DDR2-533/ PC-4200, 2 slots
|
Operator Display
|
15" TFT Touch (1024 x 768)
|
12.1" TFT Touch (800 x 600)
|
Customer Display
|
2 Lines x 20 Characters VFD
15" or 12.1" TFT with Dual display option
|
HDD
|
Type A: 160 GB or over, SATA x 1 (Max. 2 Drives)
Type B: 250GB or over, SATA x 1 (Max. 2 Drives)
|
RAID
|
Optional : Type B: 2 x 250GB or over (RAID1)*
|
Options
|
Single-sided receipt printer - double-sided receipt
printer
remote customer display - cash drawer - fixed or tilting LIU display
iButton (Dallas key) - magnetic stripe card reader - top cover
wireless cover with cable (USB) solid state flash disk (Max. 4GB)
|
Interfaces
|
2 x COM D-Sub9 (male); 2 x powered COM D-Sub9 (female)
6 x USB (2.0), 2 x powered USB (12V), 1 x powered USB (24V)
1 x PS/2 for mouse & 1 x for keyboard
2 x 24V drawer interface
1 x 15 pin VGA female type
LAN 10Base-T/100 Base-TXEthernet (RJ45) with LED
|
Audio
|
Line-out / Mic-in, 2 x stereo speakers with volume control
|
AC Inlet
|
AC inlet connector
|
Power Supply
|
95W / 105W internal switching
|
Weight
|
11.5 kg / 25.35 lbs
|
10.5 kg / 23.15 lbs
|
Dimensions
|
366 (W) x 251 (D) x 359 (H) mm
14.4"(W) x 9.88"(D) x 14.13"(H)
|
306 (W) x 247 (D) x 337 (H) mm
12.04"(W) x 9.72"(D) x 13.26"(H)
|
