Model
|
RP-3615
|
RP-3617
|
Processor
|
Intel® Celeron® M 1.5 GHz (Default)
|
System Memory
|
512 MB Standard, Maximum 2 GB (1 x 200-pin DDR2)
|
Speaker
|
Built-in 2W x 2
|
Power Supply
|
150W (12V/12.5A) External Power Adaptor
|
Storage Device
|
1 x 2.5” SATA HDD (2nd HDD as Option)
|
1 x CF Card (Optional)
|
Construction
|
Aluminum Die-casting, Plexi-Glass Acrylic (Front Bezel)
|
Housing Color
|
Black / Silver
|
Touch LCD Display
|
Size / Resolution
|
15” TFT LCD / 1024 x 768
|
17” TFT LCD / 1280 x 1024
|
Brightness
|
250 / 350 cd/m²
|
380 cd/m²
|
Touch Screen
|
5-Wire Resistive Touch / IR Touch
|
5-Wire Resistive Touch
|
I/O Ports
|
Serial
Port
|
4 x External COM1, COM2, COM5 & COM6 (RJ45)
|
USB
Port
|
4 x External
|
Printer
Port
|
1 x Enhanced Parallel Port (SCSI Ribbon 26-pin)
|
Cash
Drawer Port
|
1 x 12V RJ11 (Single/Dual)
|
PS/2
|
1 x Keyboard
|
LAN
Port
|
1 x RJ45 Giga LAN
|
Audio
Port
|
1 x Line-out
|
2nd Display
Connection Port
|
Specially Designed Connection Port
for FEC VFD or 2nd LCD Display
|
OS Supported
|
Windows
|
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
Linux
|
Per Request
|
Physical Dimensions
|
Dimensions (WxHxD)
|
375 x 390 x 255 mm
|
416 x 433 x 280 mm
|
Environment
|
EMI / Safety
|
CE, FCC Class A
|
Operating Temperature
|
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
Storage Temperature
|
-10˚C ~ 50˚C (14˚F ~ 122˚F)
|
Relative Humidity
|
10% ~ 90% (Non-condensing)
|
Optional
Peripherals
|
Magnetic Stripe Card Reader
|
MCR Single/Dual/Triple Track
|
2-in-1 / 3-in-1
|
MCR+i-Button/MCR+RFID/MCR+Fingerprint/MCR+Smartcard+i-Button
|
2nd Display / Customer Display
|
8.4”/12.1”/15” Pole-type LCD Display (Touch Screen
Optional)/
Pole-type VFD Customer Display
|
Wireless LAN
|
802.11 b/g/n Wireless LAN Module USB Interface
|
