CPU
|
Intel Pentium 4 or Celeron Processor
Shipping with P4-2.4GHz or Celeron-2.5G, FSB speed 533 / 400 MHz
|
Chipset
|
NB - Intel 82852GM
SB - Intel 82801DB
|
Memory
|
184-pin DDR DIMM x 2 , System shipping with 512MB as the standard
|
LCD
|
17 inch SXGA Color TFT-LCD, Resolution 1280 x 1024
|
Touch
|
Abon & ELO 5-wire Resistive touch (USB interface)
|
BIOS
|
Award System BIOS, 4M bits flash ROM
|
Graphics
|
1.On-Board Graphics:
Intel®852GM(E) integrated dynamic video shared memory On board LVDS connector for LCD support Max. shared memory of 64MB
2.Dual Display: support dual view, dual contents
|
Ethernet
|
On-Board Ethernet controller
|
Audio
|
On-Board Audio :
Realtek Six-channel AC`97 2.3 Audio Codec
|
HDD
|
Internal 3.5¡¨ type IDE HDD 80GB or above ,
|
I/O Interface
|
4 * COM ports (All W/DC + 5V & + 12V BIOS selection for voltage control)
1 * RJ11 port
1 * PS2 Mouse port
1 * Parallel port
1 * PS2 Keyboard port
1 * RJ-45 port
4 * Powered USB with 2 x DC+ 12V & 2 x DC + 24V
1 * MIC-IN port
1 * LINE-OUT port
1 * VGA port
|
Operation System
|
Windows XP, XP embedded, CE.Net, Linux , WEPOS, Microsoft DOS 6.22 (conditionally support).
|
Power Supply
|
AC115~230V 220watt Power supply
|
Humidity
|
Operation Humidity: 20%~85%;
Storage Humidity: 5%~80%
|
Certification
|
CE, FCC, UL, CB, VCCI, BSMI
|
