CPU
|
32-bit secure CPU, ARM9, 180MHz
|
Memory
|
Hand Set: 8MB FLASH, 16MB SDRAM
|
Display
|
128×64 pixel LCD, LED backlight and Professional icon
|
Keypad
|
10 alphanumeric keys, 9 function keys, 1 power switch key
White LED backlight
|
Magnetic Card Reader
|
Compliant with ISO7811, ISO7812; Track 1/2/3, bi-directional swipe
|
Smart Card Reader
|
1 user card(EMV2000), support SLE4442 / SLE4428 memory card
|
PSAM Slot
|
2 PSAM slots, compliant with ISO7816
|
Contactless Card Reader
(Optional)
|
Supports Mifare classic, Mifare Ultra light, Mifare DESFire, ISO 14443 A & B, SONY FeliCa
|
Internal PINPad
|
Supports MK/SK, Fixed, DUKPT
Supports dual and triple length TDES; Supports RSA
|
Communication
|
GPRS / CDMA / WiFi
Support SSL v2/3 TLSv1
|
Printer
|
High speed thermal printer
Easy-load style
Speed: up to 28 lines/sec (84mm/sec)
Paper width:58 +0/-1mm
Paper roll outside diameter: 38mm
Adjustable print gray, supports dual-layer thermal paper
|
Peripheral Port
|
2 RS-232 (up to 4), 5V @ 500mADC output
|
Power Supply
|
Input: 100 ~ 240VAC, 50Hz/60Hz;
Output: 12VDC, 3A
|
Li-ion Battery
|
2150mAh, 7.4V, more than 40 hours standby time, supports 400 transactions
|
Working Environment
|
Temperature : 0 50 ,
Humidity : 10% 90%
|
Storage Environment
|
Temperature :-20 60
Humidity : 5% 95%
|
Dimensions
|
215mm × 89.5mm × 62.8mm (L×W×H)
|
Weight
|
566g
|
Certification
|
CCC, CE, FCC, UL, RoHS, PCI PED, EMV4.2 Level1&2,PBOC2.0
|
