Model
|
RP-3512D
|
RP-3515D
|
RP-3517D
|
Processor |
Intel® Atom™ D525, 1M L2 Cache, 1.8Ghz
|
System Memory |
1 GB Standard, Maximum 4 GB (1 x 204-pin DDR3)
|
Power Supply |
90W (12V / 7.5A) External Power Adaptor
|
Storage Device |
1 x 2.5" SATA HDD
|
1 x 2.5" SATA HDD (Swappable)
|
1 x 2.5"SATA HDD (Swappable)
|
Graphics |
Intel® GMA 3150
|
Speaker |
Internal Speaker 2W x 2
|
Construction |
Aluminum Die-casting, Plexi-Glass Acrylic (Front Bezel)
|
Housing Color |
Black / Silver
|
Touch LCD Display |
Size / Resolution |
12”TFT LCD / 800x600
|
15”TFT LCD / 1024x768
|
17”TFT LCD / 1280x1024
|
Brightness (Backlight Type) |
|
250 (CCFL) / 450 cd/m² (LED)
|
350 cd/m² (CCFL)
|
Touch Screen |
5-Wire Resistive Touch
|
|
I/O Ports |
Serial Port |
2 x Internal: COM3 (Touch), COM6 (Reserved)
|
4 x External: COM2 (DB9), COM1, COM4, COM5 (RJ45)
|
USB Port |
5 x Internal, 4 x External
|
Printer Port |
1 x Bi-directional Parallel Port
|
Cash Drawer Port |
1 x RJ11 (12V)
|
LAN Port |
1 x RJ45 Giga LAN
|
PCI Slot |
Mini PCI-e (Internal)
|
Keyboard / Mouse |
1 x PS/2
|
Video Port |
1 x VGA
|
Audio Port |
1 x Line-out, 1 x Mic-in
|
DC Output |
1 x 12V DC Jack 2.5 mm
|
|
OS Supported |
Windows |
Windows XP, Windows XPE, POSReady 2009, Windows 7
|
Linux |
Per Request
|
|
Physical Dimensions |
Dimensions (WxHxD) |
325 x 345 x 255 mm
|
375 x 390 x 255 mm
|
416 x 433 x 280 mm
|
|
Environment |
EMI / Safety |
CE, FCC Class A
|
Operating Temperature |
0˚C ~ 40˚C (32˚F ~ 104˚F)
|
Storage Temperature |
-10˚C ~ 55˚C (14˚F ~ 131˚F)
|
Relative Humidity |
10% ~ 90% (Non-condensing)
|
|
Optional Peripherals |
Magnetic Stripe Card Reader |
Integrated MCR Module (Single / Dual / Triple Track Selectable)
|
2-in-1 / 3-in-1 Module |
Integrated MCR + i-Button / MCR + RFID / MCR + Fingerprint / MCR + Smartcard + i-Button
|
2nd Display |
8.4”/12.1”/15” Pole-type LCD Display (Touch Screen Optional)
|
Customer Display |
Integrated VFD / LCM Pole-type Customer Display
|
Wireless LAN |
Integrated 802.11 b/g/n Wireless Module
|
2nd Storage Device |
SATA DOM
|
