| Video System |
NTSC / PAL (auto detection) |
| Video Compression Format |
H.264 |
| Video Input |
16 channels (Composite video signal 1 Vp-p 75Ω BNC) |
| Video Loop Output |
16 channels (Composite video signal 1 Vp-p 75Ω BNC) |
| Video Output (BNC) |
Main Monitor : For stable display |
| |
Call Monitor : For sequence display |
| Video Output (VGA) |
Built-in (Output resolution up to 1600 x 1200) |
| Audio Input / Output |
4 audio inputs, 2 audio output (Mono) |
| Maximum Recording Rate |
Frame : 704×480 pixels with 120 IPS / 704×576 pixels with 100 IPS |
| |
Field : 704x240 pixels with 240 IPS / 704×288 pixels with 200 IPS |
| |
CIF : 352×240 pixels with 480 IPS / 352×288 pixels with 400 IPS |
| DCCS Support |
YES (CH1 ~ 4) |
| IVS Support |
YES (4 channels) |
| Image Quality Setting |
SUPER BEST / BEST / HIGH / NORMAL |
| Hard Disk Storage |
Accommodates 2 SATA HDDs (1 HDD capacity up to 2TB) |
| Quick Search |
Time / Motion / Alarm search mode |
| SATA Interface |
Built-in |
| Recording Mode |
Manual / Timer / Motion / Alarm / Remote |
| Multiplex Operation |
Live display / record / playback / backup / network operations |
| USB Mouse Control |
YES |
| Motion Detection Area |
16 × 12 grids per channel |
| Motion Detection Sensitivity |
3 adjustable parameters for accurate detection |
| Pre-alarm Recording |
YES |
| Backup Device |
USB 2.0 flash drive / Network |
| Web Transmitting Compression Format |
H.264 |
| Network Live Audio |
YES |
| Ethernet |
10/100 Base-T. Supports remote control and live view via Ethernet |
| Network Protocol |
TCP/IP, PPPOE, DHCP and DDNS |
| Remote Independent Operation |
YES |
| Event Notification |
By FTP / E-Mail |
| R.E.T.R. (Remote Event Trigger Recording) |
YES |
| IR Remote Control |
YES (IR receiver built-in) |
| Mobile Surveillance |
YES (Including iPhone, BlackBerry, Windows Mobile, & Symbian) |
| Remote Surveillance(Operating System: Windows 7 / Vista / XP) |
CMS : Our self-developed and free software,"Video Viewer" |
| |
Web Browser : Internet Explorer, Mozilla Firefox, Google Chrome, Apple Safari & Opera |
| |
Media Player : QuickTime |
| |
Max. on-line user : 10 |
| Picture Zoom |
2X digital zoom |
| PTZ Control |
YES |
| Alarm I/O |
16 inputs, 1 output |
| Key Lock (Password Protection) |
YES |
| User Level |
Administrator & Operator |
| Video Loss Detection |
YES |
| Camera Title |
Supports up to 12 letters |
| Image and Volume Editing |
Hue / Color / Contrast / Bright / Volume |
| Date Display Format |
YY/MM/DD, DD/MM/YY & MM/DD/YY |
| Daylight Saving |
YES |
| Power Source (±10%) |
DC 19V |
| Power Consumption (±10%) |
< 64 W |
| Operating Temperature |
10℃ ~ 40℃ (50℉~104℉) |
| Dimensions (mm)** |
432(W) × 90(H) × 326(D) |
| System Recovery |
System auto recovery after power failure |
| Optional Peripherals |
Keyboard Controller |
