Rated frequency(Hz)
|
|
5060
|
Rated voltage(V)
|
|
400/230
|
Rated current(A)
|
|
36
|
Rated output power(KVA/kW)
|
|
25/20
|
Maxoutput power(KVA/kW)
|
|
27/22
|
Rated rotation speed(r/min)
|
|
1500 1800
|
Power factor(cos)
|
|
0.8
|
Phase number
|
|
Three phase
|
Excitation mode
|
|
Brushless self-excitation
|
ATS type
|
|
With(Interface)
|
Electric engine model
|
|
KT-20
|
Structure type
|
|
Silenttype
|
Fuel tank volume(L)
|
|
65
|
Fuel consumption rate(g/kW.h)
|
|
320
|
Noise level[dB(A)@7m]
|
|
≤75
|
Dry weighe(kg)
|
|
695
|
Overall dimension(L*W*H)(mm)
|
|
1960*860*1180
|
Starting mode
|
|
24V electric start
|
Fuel |
|
0#(summer),-10#(winter),-35#(severe cold)light diesel oil |
Lube |
|
L-ecd grade 15W30 or 15W40 |
Engine model |
|
YL4100 KM496 |
Engine type |
|
Four cylinder,in-line,water-cooled,4-stroke.direct injection |
Bore*stroke(mm) |
|
100*105 95*105 |
Displacement(L) |
|
3.29 3.04 |
Compression ratio |
|
18 18 |
Rated power[kW/(r/min)] |
|
27/1500 28/1800 |
Min fuel consumption(g/kW.h) |
|
≤237
|
