Rated frequency(Hz)
|
|
5060
|
|
Rated voltage(V)
|
|
400/230
|
|
Rated current(A)
|
|
83 90.5
|
|
Rated output power(KVA/kW)
|
|
57.5/46 62.5/50
|
|
Maxoutput power(KVA/kW)
|
|
62/50 68/55
|
|
Rated rotation speed(r/min)
|
|
1500 1800
|
|
Power factor(cos)
|
|
0.8
|
|
Phase number
|
|
Three phase
|
|
Excitation mode
|
|
Brushless self-excitation
|
|
ATS type
|
|
With(Interface)
|
|
Electric engine model
|
|
KT-50
|
|
Structure type
|
|
Open-frame type
|
|
Fuel tank volume(L)
|
|
120
|
|
Fuel consumption rate(g/kW.h)
|
|
290
|
|
Noise level[dB(A)@7m]
|
|
≤84
|
|
Dry weighe(kg)
|
|
990
|
|
Overall dimension(L*W*H)(mm)
|
|
1800*800*1200
|
|
Starting mode
|
|
24V electric start
|
| Fuel |
|
0#(summer),-10#(winter),-35#(severe cold)light diesel oil |
| Lube |
|
L-ecd grade 15W30 or 15W40 |
| Engine model |
|
X4110ZD-15 |
| Engine type |
|
Four cylinder,in-line,water-cooled,turbocharged,4-stroke.direct injection |
| Bore*stroke(mm) |
|
110*130 |
| Displacement(L) |
|
4.941 |
| Compression ratio |
|
16.4 |
| Rated power[kW/(r/min)] |
|
58/1500 63.8/1800 |
| Min fuel consumption(g/kW.h) |
|
≤215
|
