Thông tin sản phẩm
•Auto L.C.R. check
•100 / 120 / 1k / 10k / 100k Hz test frequency
•20,000 / 2,000 counts display
•Backlit
•Ls / Lp / Cs / Cp / Rs / Rp / DCR with D / Q / θ / ESR measurement
•Relative mode
•Series / Parallel modes
• Components sorting function *Selectable tolerance ±0.25%, ±0.5%, ±1%, ±2%, ±5%, ±10%, ±20%, -20% +80%
• Low battery indication
• Optical IR to USB PC link (optional)
•Ω
(parallel / series mode)
|
20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ
|
•DCR
|
20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ
|
•Capacitance
(parallel / series mode)
|
200pF/2000pF/20nF/200nF/2000nF/20uF/200uF/2000uF/20mF
|
•Inductance
(parallel / series mode)
|
20uH/200uH/2000uH/20mH/200mH/2000mH/20H/200H/2000H
|
•Low battery indicator
|
Yes
|
•Over range indicator
|
Yes
|
•LCD display
|
Dual display 20,000 / 2,000 counts
|
