Thông tin sản phẩm
Phase Presence: From : 100 Vac
Nominal Voltage for Phase: To : 600 Vac
Presence Indication (The voltage required for the neon Lamps L1, L2, L3 to light up): Frequency : 10-400 Hz
Determination of Phase: From : 1 Vac
Rotation Field: To : 450 Vac
Direction: Frequency : 2-400 Hz
Determination of Motor Connections (requires > 1/2 turn of the shaft): From : 1 Vac, To : 600 Vac, Frequency : 2-400 Hz
Maximum Current Consumption: 18mA
Over Voltage CLASS III: 600V
Over Load between all terminals: 600V
Battery Ok goes off when battery voltage: < 6.5 Vdc
Power Source: 9V (6F22.006P) x 1 battery
Dimensions: 153(L) x 72(W) x 35(D) mm
Weight: Approx. 185g (battery included)
Accessories: Test leads (AL-34), Vinly case, Instruction manual, Battery
