Image Sensor |
1/5"Color CMOS Sensor |
| Display Resolution |
640*480 Pixels(300k Pixels) |
| Lens |
f: 2.8mm, F:2.4 (IR Lens) |
| Mini. Illumination |
0.5Lux |
| Lens |
Lens Type |
Glass Lens |
| Viewing Angle |
50 Degree |
| Audio |
Input |
Built-in Microphone |
| Output |
Built-in Speaker， with a audio jack |
| Audio Compression |
ADPCM |
| Video |
Image Compression |
MJPEG |
| Image Frame Rate |
15fps(VGA),30fps(QVGA) |
| Resolution |
640 x 480(VGA), 320 x 240(QVGA) |
| Flip Mirror Images |
Vertical / Horizontal |
| Light Frequency |
50Hz, 60Hz or Outdoor |
| Video Parameters |
Brightness, Contrast |
| Communication |
Ethernet |
One 10/100Mbps RJ-45 |
| Supported Protocol |
HTTP,FTP,TCP/IP,UDP,SMTP,DHCP,PPPoE,DDNS,UPnP,GPRS |
| Physical |
Pan/Tilt Angle |
Horizontal:300° & Vertical: 120° |
| Infrared Light |
11 IR LEDs,Night visibility up to 8 metres |
| Dimension |
110(L) x100(W) x108mm(H) |
| Gross Weight |
750g (Color Box Size:200X120X175mm) |
| Net Weight |
400g (accessories included) |
| Power |
Power Supply |
DC 5V/2.0A (EU,US,AU adapter or other types optional) |
| Power Consumption |
7 Watts (Max.) |
| POE |
POE Standard |
IEEE 802.3af |
| Input Voltage |
DC 36V~DC 57V |
| Output Voltage |
DC 5V |
| Output Power |
15.4W (Max.) |
| Wiring Standards |
100M BASE-T |
| Environment |
Operate Temper |
0° ~ 55°C (14°F ~ 122°F) |
| Operate Humidity |
20% ~ 85% non-condensing |
| Storage Temper |
-10°C ~ 60° (14°F ~ 140°F) |
| Sstorage Humidity |
0% ~ 90% non-condensing |
| PC Requirements |
CPU |
2.0GHZ or above (suggested 3.0GHz) |
| Memory Size |
256MB or above (suggested 1.0GHz) |
| Display Card |
64M or above |
| Supported OS |
Microsoft Windows 2000/XP,Vista,Windows7,Mac OS,Linux |
| Browser |
IE6/IE7/IE8,Firefox,Safari,Goolge Chrome,other standard browsers |
| Certificate |
CE,FCC |
