Type
|
IP Carema - ONVIF 2.2
|
|
|
Parameter
|
Image Sensor
|
1/3" CMOS Digital Image Sensor(SONY)
|
|
|
Pixels
|
1080P / 720P
|
|
|
minimum illumination
|
0.01Lux
|
|
|
S/N
|
≥45db
|
|
|
IR
|
>10M
|
|
|
IR-Cut
|
Color to BW:2Lux; BW to Color:6Lux
|
|
|
Optical Lens
|
Interface
|
M12
|
|
|
Lens
|
Fixed Iris Lens
|
|
|
Focal length
|
3.6mm,6mm optional
|
|
|
Network
|
Network interface
|
RJ45 10M/100M
|
|
|
Network Protocol
|
HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPoE,IPv4/v6,SNMP,QoS,UPnP,NTP
|
|
|
ONVIF
|
Supports
|
|
|
Network Preview
|
Web server embedded, Support IE
|
|
|
Domain name server
|
Supportzeisic,88110,reelink,3322, dyndns, no-ip, changeip, dnsexit domain name server as default value.
|
|
|
Video
|
Video encode
|
H.264 Baseline Profile/H.264 Main Profile
|
|
|
Resolution
|
Main stream:720p @ 30fps; Sub stream:VGA/QVGA@ 30fps/720P @8fps
|
|
|
Bitrate
|
Main stream:500Kbps～6000Kbps; Sub stream:159Kbps～1600Kbps
|
|
|
CBR/VBR
|
Support
|
|
|
Alarm
|
NO
|
|
|
|
|
Others
|
Operation Temperature
|
-10℃--＋55℃
|
|
|
Operation Humidity
|
0% - 90%
|
|
|
Power supply
|
DC 12V / PON(power by NVR mainboard)
|
|
|
Protection
|
IP66
|
|
|
Power
|
<5w
|
|
|
Dimension
|
unfolded: Φ60*151.3MM; fold: Φ60*113.2MM
|
|
|
