| Standard Features |
DI 730 II 2WD |
| Engine |
| Engine Type |
2105 DL Without coldstart |
| HP Category |
30 |
| No. of Cylinders |
2 |
| Aspiration |
Natural Aspiration |
| Bore/Stroke(mm) |
105/118 |
| Cubic Capacity (cc) |
2044 |
| Rated RPM (+/-25mm) |
2100 |
| Air cleaner |
wet Air Cleaner |
| Max Torque (Nm) @ RPM |
112(+/-5%)@1300 RPM(+/-100) |
| Transmission |
| Drive |
2WD |
| Clutch |
Single Clutch |
| Gearbox |
8F+2R |
| Transmission |
Sliding Mesh |
| PTO |
| PTO (rpm) |
540 rpm |
| PTO (actuation) |
Mechanical,Hand operated |
| Diff Lock |
| Diff. Lock(mechanical) |
No |
| Electrical |
| Battery |
12V,75 AH |
| Alternator |
12V,35 Amp |
| Seven pin trailer socket |
Yes |
| DCV |
| Auxiliary hydraulic circuit |
NO |
| No.of Spool valves |
NO |
| Steering |
| Steering |
Mechanical Steering |
| Tyre |
| Front |
6*16 |
| Rear |
12.4*28 |
| Speed(Forward) |
| Max Speed(Km/Hr) |
29.60 @ 2000 |
| Min Speed(Km/Hr) |
2.75 @ 2000 |
|
|
| Hydraulics |
| 3 point linkage |
CAT2 |
| Stay Bars |
Yes Adjustble Check Chain |
| Hydraulic lifting capacity |
1200 kg |
| Brakes |
| Brakes |
Dry Disc Brake |
| Type of actuation |
Mechanical |
| Hand brake |
Yes |
| Others |
| Driver Seat |
Yes, Adjustable With Smv |
| Trailer hitch |
Standard Rear Toe Hook |
| Fuel Indicator gauge |
Yes |
| Canopy |
No |
| Registration Plate with light |
No |
| Front Toe Hook |
Yes |
| Front & rear weights |
Bumper Only |
| Drawbar |
Normal draw Bar |
| ROPS |
No |
| Safety Switch |
| Neutral safety switch |
No |
| P.T.O Safety switch |
No |
| Clutch Safety Switch |
No |
| Capacity (ltrs)(+/-5%) approx |
| Fuel tank |
55 |
| Eng Oil |
6 |
| Hyd+Tran |
50.3 |
| Dimension & Weight(+/-5%) |
| Gross Weight(kg) |
1800 |
| Wheel Base (mm) |
1835 |
| Total Length (mm) |
3375 |
| Total Width (mm) |
1655 |
| Height (mm) |
2305 |
| Ground Clearance (mm) min |
370 (below trans. Plug) |
| Front Track, (mm), min.-max. |
1300 (std.) & 1500 |
| Rear Track, (mm), min.-max. |
1325 (std.) 1475-1535 |
| Turning Diameter |
| Without Brakes (m) |
6.5 m ( R ) – 6.11 m ( L ) |
| Turning diameter. With Brakes (m) |
5.57 m ( R ) – 5.49 m ( L ) |
