Native Resolution:
|
1024 x 768 XGA
|
|
Supported Resolutions:
|
SXGA, XGA, SVGA, VGA, Mac
|
|
Brightness:
|
3000 lumens
|
|
Lamp:
|
200W NSH Lamp
|
|
Lamp Life:
|
2000 hours (normal)
3000 hours (ECO mode)
|
|
Display Type:
|
3X0.63” MLA
HTPS TFT LCD
|
|
Contrast Ratio:
|
500:1
|
|
Colors:
|
16.7 million
|
|
Aspect Ratio:
|
4:3 native
16:9 compatible
|
|
H-Sync
Range:
|
15-69 kHz
|
|
V-Sync
Range:
|
43-85 Hz
|
|
Inputs:
|
2-RGB D-Sub (2nd for RGB and Y Pb Pr)
1-Phone-jack audio
1-Composite AV
1-S-Video
1-RS-232
|
|
Outputs:
|
1-RGB computer out,
1-Mini-jack audio
1-USB mouse
|
|
Speakers:
|
1 – 2 watt speaker
|
|
Special features
|
Auto Keystone
Auto Brightness
Auto Ceiling
Auto image Optimize
|
|
Noise:
|
30 dB in economy mode
|
|
Weight:
|
2.9kg (6.4lb)
|
|
Dimensions:
|
310(W) x 96(H) x 270(D)
mm
|
|
Projector Lens:
|
Manual zoom and focus,
Zoom ratio: 1:1.2
F/1.6~1.88, f=18.6~22.3mm
|
|
Image Size:
|
40 - 300 inches (diagonal)<60”@1.7M>
|
|
Throw Distance:
|
1.1-10.5M
|
|
Keystone Adj.:
|
Digital adjustment:
Vertical +/- 30 degrees
|
|
Adjustments:
|
on-board / remote / RS-232 Wire
|
|
Power Supply:
|
100-240V at 50-60Hz
|
|
Power Consumption:
|
250 watts
|
|
HDTV/EDTV Compatibility:
|
1080i, 720p, 576i/p , 480i/p
|
|
Video Compatibility:
|
NTSC, NTSC 4.43, PAL-I, PAL-M/N, PAL-D/K,
PAL-B/G SECAM
|
|
Workstation Compatibility:
|
Yes
|
|
Regulations
|
UL / FCC class B / CE / CB
|
|
Interactive Projector
|
|
Light Emitted
|
Infrared
|
|
Control Buttons
|
1 button
|
|
Power Requirement
|
1.5V size AAA battery x 2
|
|
E-wand extendable length
|
62cm ~ 92cm (TBD)
|
|
Weight
|
60g (without battery) (TBD)
|
|
System Requirements
|
|
OS Required
|
Microsoft Windows 98/2000/XP
|
|
Processor Type
|
Intel Pentium or above
|
|
RAM Size
|
128 MB (256 MB or above recommended)
|
|
Min. Hard Drive Space
|
30 MB CD-ROM Driver & available USB 2.0
port
|
|
Recommended Signal Reception
Range
|
|
Projection Size
|
Distance between screen and Projector
|
|
60”
|
1.7 m
|
|
80”
|
2.3 m
|
|
100”
|
2.9 m
|
|
120”
|
3.5 m
|
|
Package Contents
|
Projector built in with interactive
whiteboard
E-wand x 1 with AAA battery x 2
Driver CD-Rom x 1
1.5M USB Cable X 1
User’s Manual
|
