Ⅰ:Technical parameters:
Control System: |
PLC |
Foaming System: |
1 Set |
Water spray wax: |
1 Set |
High Pressure Water Pump: |
Taiwan |
Machine Casing: |
Hot Dip Galvanized And Outdoor Powder Paint |
Colour: |
Red/ Yellow/ Bule/ White/ Green |
Main Electrical: |
Schneider |
Machine Size: |
6080MM*3580MM*2850MM (L*W*H) |
Vehicle Size: |
6300MM*4000MM*2850MM (L*W*H) |
Remote Control System: |
1 Set |
Wash Type: |
car,jeep,coach below 10 seats |
Washing Ways: |
2 roll over shampoo wash |
Water Consumption: |
120L/set |
Power Consumption: |
0.15kwh/set |
Shampoo Consumption: |
7ml/set |
Wax Consumption: |
12ml/set |
Total Electrical Capacity: |
8.55KW |
Power Requied |
AC380V50Hzvolume 15KVA |
Water Requied |
Pipe diameter DN25 flow≥100L/min |
Air Requied |
Pressure 0.75-0.9Mpa/flow≥0.1m3/min |
Ⅱ: Product introduction:
AT-WU05 Touchless car wash machine is qualified to wash and spray foam,
water and wax automatically, which covers small space and operates easily, there is no
need for customer to the paint destroyed by the brush since it is brushless. The
dual-swing-arm spraying system ensure the easy and complete full-scope cleaning.
Ⅲ:Feature:
1. The machine is controlled by intelligent CUP.
2. Swing arm move in 360 round, can clean anywhere of cars.
3. Cover a small area, saving space and easy to operation.
4. Bottom wash and high pressure water gun are as optional.
