Working surface of table
|
200 x 450 mm
|
Max. surface ground
|
200 x 450 mm
|
Max. distance center of spindle to table
|
450 mm
|
Table speed
|
5~25 M/min
|
Table guideway
|
V&flat way
|
Auto. cross feed increment (approx.)
|
0.1 mm x 12 mm
|
Rapid power cross feed (approx.)
|
1100 (60 Hz) / 900 (50 Hz)
|
Cross feed on hand wheel (1 rev)
Cross feed on hand wheel (1 gra)
|
5 mm
0.02 mm
|
Rapid power head elevation (opt., approx.)
|
550 mm/min (60 Hz)
450 mm/min (50 Hz)
|
Vertical feed on hand wheel (1 rev)
Vertical feed on hand wheel (1 gra)
|
2 mm
0.01 mm (standard) / 0.005 mm (with AD5 option.)
|
Auto. down feed (opt.)
|
0.001 mm ~ 0.999 mm/time
|
Wheel speed
|
3500 r.p.m. (60 Hz) / 2900 r.p.m. (50 Hz)
|
Wheel dimension
|
180 x 13 x 31.75 mm (max. 200 x 20 x 31.75)
|
Spindle motor
|
2 HP
|
Hydrauilc pump motor
|
1 HP
|
Auto. cross feed motor
|
25 W
|
Rapid head elevation motor
|
1/5 HP (opt.)
|
Coolant pump
|
1/8 HP (opt.)
|
Machine net weight
|
950 kg
|
Machine floor space
|
2100 x 1300 mm
|
