Keyboard
|
61 keys semi–weighted
Velocity sensitive and after touch are supported
|
|
System
|
Upgradable Operating System
RX (Real eXperience)
DNC (Defined Nuance Control)
Multitasking - Load while play feature
|
|
Tone Generator
|
KORG EDS (Enhanced Definition Synthesis) sound generator
128 Voices, 128 Oscillators
Filters with Resonance
Three band EQ for each track
|
|
Effects
|
Up to 4 Stereo Digital Multi-Effect block systems
125 Master Effect types + 2 Global Effects
|
|
Voice Processor
|
Three-part Harmonizer by TC Helicon® with 4 Effects: Reverb, Delay, plus Compressor, and EQ
|
|
Sounds / Drumkits
|
More than 1100, including Stereo Piano and GM/GS improved sound compatibility; more than 70 Drum Kits
User area: 512 Sounds, 128 Drum Kits
Defined Nuance Control (DNC) Technology
Digital Drawbars: 9 Footages
Full Sounds/Drumkits editing capability
User PCM RAM Memory: 192 MB
|
|
Full Sampling Editing
|
Compatibility: Load/Import of Korg, Wav, AIFF and SoundFont™; Export of Wav and AIFF; Edit, Time Slice, Compression Tool.
|
|
Styles
|
More than 400 preloaded Styles, freely reconfigurable
1200 available Style locations including the Favorite banks
Eight Style tracks, 4 Single Touch Settings, 4 Pads and one Style Setting per Style
Guitar Track 2 mode, Parallel and Fixed NTT
Style Record with Step Record, Track and Event Edit functions
Style controls: 3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Synchro Start/Stop, Tap Tempo/Reset, Bass Inversion, Auto Fill, Manual Bass, Memory, Accompaniment Mute, Drum Mapping, Snare & Kick Designation, STS Mode
|
|
Chord Sequencer
|
Real-time Style Chord Sequencer Recorder
|
|
Performance / STS
|
320 Realtime Performance locations
STS: Memorize Keyboard tracks settings, up to 4 x 1200 Styles, up to 4 x SongBook entries,"My Setting" function
|
|
Song Play
|
Patented XDS Crossfade Dual Sequencer Player (Supported formats: MID, KAR, MP3 + lyrics, MP3+G)
2 Players with separate Select, Start/Stop, Home, Rewind and Fast Forward controls
X-Fader Balance control
Lyrics, Score, and Chord data can be displayed on screen, or on external video monitor
Markers
Jukebox function
|
|
Mp3 Player / Recorder
|
Double Mp3 Player and Mp3 Recorder
Real Time Transpose (+6/-5 semitones)
Tempo change (±30%)
Vocal Remover
Record MP3 files including Styles, SMF, Real Time Tracks, Pads, Microphone and Effects
|
|
Sequencer
|
Quick Record (Backing Sequence)
Multitrack and Step Record functions - Full-featured sequencer
16 tracks; Up to 200,000 events
SMF native format
|
|
SongBook
|
Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes
User-definable custom lists
Filtering and Ordering options
|
|
Compatibility
|
"i-Series" models: Styles
Pa series: Style, Performance, Program/Sound, Song, SongBook, Pad
|
|
Multi Pad
|
4 Assignable Pads + Stop Button - Pad Record function
|
|
General Controls
|
Master Volume; Fade In/Out; Keyboard-Acc/Song Balance Volume; Ensemble; Octave Transpose; Master Transpose; Style Change; Quarter Tone and Arabic Scale memorized inside Performance/STS; Real-time controllers: Joystick (pitch + modulation); Mic Volume; Mic FX Volume; Mic On/Off; Mic Preset; Mic Harmony On/Off; 3 Assignable Switches; Tempo +/-; Tempo Lock; Dial; Search Function; Shift; Chord Scan; Split; Metronome On/Off; Sound Select
|
|
Control Inputs
|
Damper pedal (support half-pedaling with optional DS-1H pedal)
Assignable pedal/switch
|
|
Outputs
|
Audio Output: Left/Mono, Right/Mono, Unbalanced
Headphone Output: 1 (in the front panel)
Video Out: 1 RCA type
|
|
Mic/Line Inputs
|
2 Unbalanced Jack; Left/Mono-Mic, with gain control and Right/Mono
|
|
MIDI
|
In, Out; standard Midi connectors
USB to Midi using the USB Device port
8 user definable MIDI Setups
|
|
USB
|
USB-MIDI Interface
To Device: 1 (Front)
To Host: 1 (Rear)
2.0 Hi Speed connections
|
|
Mass Storage/Disk
|
Micro SD, back panel slot
|
|
Display
|
Color TouchView™ 7" TFT display
|
|
Clock
|
Internal System Clock
|
|
Amp/Speaker System
|
Amplification:20W x 2 - Speakers:100 mm x 2 woofer in Bass Reflex Box, Dome tweeter x 2
|
|
Power Consumption
|
20 Watt; 100-240v 50/60 Hz
|
|
Dimensions
|
1,030 x 378.3 x 138.8 mm / 40.55 x 14.89 x 5.46 inches (without music stand) - (W x D x H)
|
|
Weight
|
10,76 kg / 23.72 lbs
|
|
Accessories
|
Manual, AC Power Cable, Music Stand, DVD-ROM
|
|
Options
|
EXP-2 - Expression/Volume Pedal
XVP-10 - Professional Expression/Volume Pedal
DS-1H - Damper Pedal
PS-1/PS-3 Switch Pedal
|
