Các thông số chức năng |
Loại cảm biến hình ảnh |
Color CIS (Contact Image Sensor : cảm biến hình ảnh tiếp xúc màu sắc) x 2 (front x 1, back x 1) |
Nguồn sáng |
3 Color LED (Red / Green / Blue) x 2 (front x 1, back x 1) |
Độ phân giải quang học |
600 dpi |
Độ phân giải ngõ ra |
Color (24-bit) |
50 to 600 dpi
(adjustable by 1 dpi increments), 1200 dpi (driver) |
Grayscale (8-bit) |
Monochrome |
Độ sâu màu sắc ngõ ra |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
Internal Video Processing |
1024 levels (10-bit) |
Chức năng xử lý ảnh |
Deskew, Cropping, Image emphasis, Error diffusion, Dither, Black & White Method, Dynamic threshold (iDTC), Static threshold, Advanced DTC, SDTC, De-Screen, Dropout color (Red / Green / Blue / White / None / Saturation / Custom), Automatic color detection, Multi image output, Blank page detection, sRGB output, Split image, Front/Back Merging |
Tốc độ quét
(A4, Portrait) |
Color
Grayscale
Monochrome |
ADF |
Một mặt : 27 ppm, Hai mặt : 54 ipm
(200 dpi / 300 dpi) |
Dung lượng ADF |
50 Tờ ( A4: 80 g/m² or 20 lb. ) |
Daily Duty Cycle |
2,500 trang |
Kích thước tài liệu |
ADF Minimum |
50.8 mm x 50.8 mm (2 in. x 2 in.) |
ADF Maximum |
216 mm x 355.6 mm (8.5 in. x 14 in.) |
Long Document |
216 mm x 5,588 mm (8.5 in. x 220 in.) |
ADF Feeding
Paper Weight
(Thickness) |
Giấy |
40 g/m² to 209 g/m² (11 lb. to 56 lb.), A8 size : 127 g/m² to 209 g/m² (34 lb. đến 56 lb.) |
Thẻ nhựa |
0.76 mm hoặc nhỏ hơn, Embossed card: usable, Multiple cards cannot be set at a time |
Cổng kết nối |
USB2.0 / USB1.1 |
Thông số cấu hình PC tối thiểu |
PaperStream Capture, i5 2.5 GHz Processor, 4 GB RAM |
Các thông số vật lý |
Thông số nguồn điện |
100 đến 240 VAC ±10 % |
Mức độ tiêu hao điện năng |
17 W hoặc thấp hơn, chế dộ Sleep: 1.1 W; Auto standby (OFF): 0.15 W hoặc thấp hơn |
Kích thước (WxDxH) |
290 x 146 x 130 mm (11.41 x 5.74 x 5.11 in.) |
Khối lượng |
2.9 kg (6.4 lb) or less |
Thân thiện môi trường |
ENERGY STAR® / RoHS |
Điều kiện môi trường hoạt động |
Nhiệt độ |
5 to 35°C (41 to 95°F) |
Độ ẩm |
20 %-80 % (non-condensing) |
Phụ kiện đi kèm |
ADF paper chute, cáp AC, AC adapter, cáp USB, đĩa cài đặt DVD-ROM,
Hướng dẫn cài đặt nhanh, Safety Precaution |
Phần mềm đi kèm |
PaperStream IP (TWAIN/ISIS) Driver, Software Operation Panel, Error Recovery Guide, PaperStream Capture, ScanSnap Manager for fi Series, Scan to Microsoft SharePoint, ABBYY FineReader for ScanSnap, Scanner Central Admin Agent |
Chức năng tùy chọn |
2D Barcode for PaperStream, Carrier Sheet |
Hệ điều hành được hỗ trợ |
Windows® 10 (32-bit/64-bit),Windows® 8 / 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Vista® (32-bit/64-bit), Windows Server® 2012 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2008 (32-bit/64-bit), Windows Server® 2008 R2 (64-bit) |
