Thông tin sản phẩm
LCD Size
17"
Max Resolution
1280 x 1024
Brightness (cd/㎡)
300
Contrast Ratio
800 : 1
LCD Color
16.7M
Pixel Pitch (mm)
0.264(H) x 0.264(V)
Viewing Angle (H-V)
160/160
Backlight MTBF
50000
CPU
IntelR Core 2 Duo T7500 2.2GHz
IntelR Celeron M 575 2.0GHz
IntelR Core 2 Duo T9400 2.53GHz CPU
Chipset
IntelR GM45 Chipset + ICH9M
RAM
Supports two 2.0GB 667MHz or 800MHz DDR2 SO-DIMM (System max. 4.0GB)
I/O Ports and Switches
1 x RS232 COM Port
1 x RS-232/422/485 COM port
2 x Giga LAN
4 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x VGA port
1 x Audio port
1 x HDMI port
1 x Display port
SSD
CF TypeII
Watchdog Timer
Software programmable supports 1~255 sec. System reset
Audio
AMP 2W + AMP 2W
Expansion
1 x Wireless Lan Module (Mini PCIe Interface, 802.11 b/g /n LAN Module)
1 x Bluetooth Module (USB Interface, Bluetooth V2.0)
HDD Drive Bay
1 x 2.5" SATA HDD bay
1 x Slim Type CD-ROM bay
Construction Material
ABS + PC Plastic front frame
LED Function
1 x Power ON/OFF LED on Front Panel
Mounting
Panel, Wall, Rack, Stand and Arm (VESA 100mm x 100mm)
Front Panel Color
Sliver
Dimension (WxHxD) (mm)
428 x 350 x 79
Operation Temperature
0℃ ~40℃ With HDD
0℃ ~45℃ With CF Card or SATA interface 2.5" SSD HDD
Storage Temperature (℃)
-20℃ ~60℃
EMC
CE, FCC, CCC
Net Weight
7.5 Kg
IP Level(front panel)
IP64
Safety
CB
Touch Screen
Resistive Type 5-Wire (Touch controller IC is on board)
Power Adapter
P/N:63000-FSP150AHA312-RS
Power: 150W
Input: 90VAC~264VAC, 50/60Hz
Output: 12VDC
On Screen Display
OSD Keypad below the Front Panel
Membrane Keypad
LCD On/Off, Brightness Up/Down, Volume Up/Down
Power Requirement
12VDC
Power Consumption
108W
HSDPA Mobile Solution (Optional)
1 x HSDPA Mobile Module (USB Interface)
