| CPU Support |
Intel® Atom™ processor 1.1GHz/ 1.6GHz with 512 KB on-die L2 cache, 400MHz/ 533MHz FSB |
| Chipset |
Intel® System Controller Hub US15W (single chip integrated graphics and I/O controller) |
| Memory |
1GB DDR2 SODIMM 667MHz, support up to 2GB (optional) |
| Storage |
8GB Solid State Drive/ SATA interface, up to 64GB (optional) |
| Audio |
ALC888-VC2-GR HD Codec AC '97 Compatible 2 x 2w built-in speaker 1 x external Mic-in and 1 x external Line-out |
| Display |
8.4" TFT LCD with CCFL backlight; Resolution: 800 x 600
(SVGA); Luminance: 400 nits; Contrast Ratio: 500:1 Touch Screen: Analog
Resistive 4 wire daylight readable touch screen Auto dimming via
ambient light sensor |
| I/O |
2 x External USB 2.0 port; 1 x Mini USB (Client) 1 x Mic-in and 1 x Line-out 1 x 19V DC power input |
| Communication |
Bluetooth Module class 2 V 2.1 + EDR IEEE 802.11 b/ g/ n
Wi-Fi Module with built-in antenna WWAN module support of GSM/ GPRS/
HSDPA/ WCDMA (optional) |
| Data Capture |
GPS receiver with built-in internal antenna 2M pixel
CMOS camera HF RFID reader compliant with ISO14443A/B and ISO 15693
(optional) 1D/ 2D laser barcode engine (optional) Fingerprint Sensor |
| Indicators and Buttons |
Four LED indicator - Power on/ off, Battery, WLAN and
HDD Four Programmable Function Keys Five Buttons – navigation key, power
button, wireless switch button, camera shot button and barcode scanner
button |
| Power Input |
Power Input Voltage: DC 19V/ 3.42A Power Output: 65W (Max) Rechargeable Lithium Ion Smart Battery Pack: 2600 [email protected], 28.86W |
| Dimensions |
289mm (W) x 214mm (H) x 46mm (D) with Rubber 280mm (W) x
205mm (H) x 37mm (D) without Rubber Weight: 1.65Kg with Rubber; 1.35Kg
without Rubber |
| Enclosure |
Plastic housing (ABS + PC) Color: Black |
| Environment |
Operating Temp: -20°C to 50°C Storage Temp: -30°C to 60°C Rel. Humidity: 5% to 95% |
| Rugged Grade |
IP54 4 feet drop to polywood Compliant with MIL-STD-810F |
| Certifications |
CE approval FCC Class B |
