Audio options
Speaker, Headset jack, Bluetooth, Rugged audio connector, Speakerphone
Display type
PenTile® 3 in. diagonal color display, touch, VGA 640 x 480 portrait, Super Bright 750+ NITS (luminous)
Weight
Standard Battery: 5.5 oz./156 g;Extended Battery: 6.5 oz./188.5 g
Expansion slot
microSD - supports up to 32GB
Headset
Bluetooth headset, Wired headset |
|
Dimensions (HxWxD)
Standard Battery: 5.08 in. L x 2.38 in. W x 0.67 in. D; 129 mm L x 60.4 mm W x 16.5 mm DExtended Battery: 5.08 in. L x 2.38 in. W x 0.85 in. D; 129 mm L x 60.4 mm W x 21.5 mm D
Display resolution
VGA 640 x 480 portrait
Keypad options
QWERTY, AZERTY, QWERTZ
Notification
Vibrator, Audio notifications, Programmable LEDs
Device security
Biometric (finger swipe) and PIN code |
CPU
600 MHz, ARM 11 processor, MSM 7627
Environmental sealing
Meets IP42 sealing requirements
Storage temperature
-40º F to 158º F/-40º C to 70º C
Vibration
MIL-STD 810G Method 514.5, figure 514.5C-1; 1 hour per axis |
|
Drop specification
Military Standard (MIL-STD) 810G 4 ft./1.22 m drop specification; 3 ft./0.91 m drop to vinyl covered concrete across the operating temperature range (36 drops at 32º F/0º C, room temperature and 104º F/40º C)
Operating temperature
32º F to 104º F/0º C to 40º C
Tumble specifications
150 1.65 ft./0.5 m tumbles (equivalent to 300 consecutive drops) at room temperature; meets and exceeds applicable IEC tumble specifications |
Interfaces
Motorola Enterprise UI; customizable home screen, enhanced dialer and enterprise camera solution
Operating system (OS)
Microsoft Windows Mobile 6.5.3 Professional
Data capture options
1D/2D bar code scanning, 3.2 MP autofocus digital camera for photos and videos, Document and signature capture
Interfaces
Motorola Enterprise UI; customizable home screen, enhanced dialer and enterprise camera solution
|
|
CPU
600 MHz, ARM 11 processor, MSM 7627
Memory
256MB RAM/1GB Flash
Memory
256MB RAM/1GB Flash
Processor (CPU)
600 MHz, ARM 11 processor, MSM 7627 |
Main battery
Standard: Rechargeable Lithium Ion 1540mAhbattery @ 3.7 V;Extended: Rechargeable Lithium Ion 3080mAhbattery @ 3.7 V |
|
|
Handheld Warranty
The ES400 is warranted against defects in workmanship and materials for a period of 12 months from date of shipment, provided that the product remains unmodified and is operated under normal and proper conditions. |
|
|
Security
WPA2 (Personal or Enterprise); 802.1x; EAP-TLS; TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5); PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP, EAP-FAST (TLS, MS-CHAPv2, EAP-GTC)
WPAN (Bluetooth Support)
Integrated antenna, Class II, v2.0 with Enhanced Data Rate (EDR) |
