Physical Characteristics
|
Dimensions:
|
18.65 cm * 7.5 cm * 3.9 cm
|
Weight:
|
400g (included battery and scanners)
|
Display:
|
Color 3.2″QVGA TFT-LCD with backlight, 65K colors, 240 W x 320 L (QVGA size)
|
Input Method:
|
Touch input and keyboard input
|
Expansion Slot:
|
PSAM, SIM, MicroSD/TF
|
Interfaces:
|
USB2.0; RS-232
|
Battery:
|
Rechargeable li-ion polymer battery 3.7V/4000mAh
|
Audio:
|
0.5 watt
|
Keypad:
|
numeric, full A-Z alphanumeric (Optional)
|
Performance Characteristics
|
CPU:
|
Samsung ARM920T@533MHz
|
RAM:
|
128MB
|
Memory:
|
1GB NAND FLASH, MicroSD/TF slot, maximum 32G
|
User Environment
|
Operating Temp:
|
-25℃ to 50℃
|
Storage Temp:
|
-25℃ to 70℃
|
Humidity:
|
5%RH to 95%RH non-condensing
|
Drop Spec:
|
1.5 meter drop to concrete, 6 drops per 6 sides over operating temperature range
|
Tumble Spec:
|
1,000 0.5m tumbles
|
Sealing:
|
IP64
|
Programming Environment
|
Operating System:
|
Windows Embedded CE 6.0
|
SDK:
|
Chainway Software Development Kit
|
Language:
|
C++, C#, VB.NET, JAVA
|
Tool:
|
Visual Studio 2005/2008
|
1D Linear Scanner
|
1D CCD scanner:
|
Symbol SE655 (Optional)
|
Optical resolution:
|
5Mil min width
|
Roll tolerance:
|
±25º
|
Pitch tolerance:
|
±65º
|
Skew tolerance:
|
±30º
|
Ambient light:
|
0ft.candles-10000ft.candles
|
Scan repetition rate:
|
50 per second
|
Scan angle:
|
53º±3º
|
Barcode type:
|
UPC/EAN, Bookland EAN, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Matrix 2 of 5, Inverse 1D, MSI, GS1 DataBar, etc.
|
1D laser scanner:
|
Symbol SE955 (Optional)
|
Optical resolution:
|
4Mil min width
|
Roll:
|
100%UPC (5in. ±35º)
|
Pitch Angele:
|
100%UPC (5in. ±65º)
|
Skew tolerance:
|
100%UPC (5in., ±50º)
|
Ambient light:
|
10000ft.candles (107640 lux)
|
Scan repetition rate:
|
scan 104 per second (±) 12 times (two-way)
|
Scan angle:
|
47º±35º(standard)/ 35º±3º (narrow-angle)
|
Barcode type:
|
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS
|
2D Imager Scanner
|
CMOS laser scanner:
|
Symbol SE4500
|
Sensor resolution:
|
752 (horizontal ) * 480 (perpendicular) pixel (gray level)
|
Roll tolerance:
|
360º
|
Pitch tolerance:
|
±60º
|
Skew tolerance:
|
±60º
|
Ambient light:
|
9000ft.candles/96900 lux (lightless)
|
Aiming LED (VLD):
|
655nm ± 10nm
|
Illumination element:
|
650nm ± 5nm
|
Field of view:
|
40º horizontal, 25º perpendicular
|
Barcode type:
|
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX)
|
Decode ranges:
|
SR Focus
|
Near
|
Far
|
5 mil Code 39
|
2.1 in./53 mm.
|
7.5 in./191 mm.
|
100% UPC/ENA
|
1.6 in./41 mm.
|
15.5 in./394 mm.
|
6.7 mil PDF417
|
3.4 in./86 mm.
|
7.1 in./180 mm.
|
|
Camera
|
|
3.2MP camera 2048(H)*1536(V), QXGA
|
RFID
|
LF
|
|
Frequency:
|
125kHz ~ 134.2kHz
|
|
Protocol:
|
ISO11784/5
|
|
Distance:
|
0 cm~8 cm for FDX-B; 0 cm~16 cm for HDX
|
|
HF (Optional)
|
|
Frequency:
|
13.56MHz
|
|
Protocol:
|
ISO14443A/B, ISO15693 (Optional)
|
|
Distance:
|
0 cm~8 cm
|
|
WIFI
|
|
Protocol:
|
IEEE802.11 b/g
|
|
GPRS
|
|
Frequency:
|
GSM/GPRS (850,900,1800,1900MHz) 85.61/42.8bps
|
|
Bluetooth
|
|
|
Class 2.0+EDR, 3~5 m
|
|
GPS
|
|
GPS:
|
low energy GPS chip
|
|
Regulatory
|
|
EMC:
|
ETSI EN 301 489-1, ETSI EN 301 489-3, ETSI EN 301 489-17, EN 55022, EN 55024
|
|
Health and Safety:
|
EN 62311, EN 62209-2, EN 60950-1, EN 62133
|
|
Wireless and RF:
|
ETSI EN 300 328, ETSI EN 300 330-1, ETSI EN 300 330-2,ETSI EN 300 440-1, ETSI EN 300 440-2
|
|
Standard accessories
|
|
Power Adapter:
|
1
|
|
Data Cable:
|
1
|
|
MicroSD(TF) card:
|
1
|
|
Carrying Case:
|
1
|
|
Optional accessories
|
|
|
Cradle (docking station)
|
|
|
Single unit charger (battery charger)
|
|
