Main Function:Ditching, earth up
Main Application Range:Vegetable field,orchard,tobacco field,etc.
Features:
1)A vertical output axle, all gear system, double power output.
2)Small volume,light weight,compact structure.
3)Automatic clutch,stepless speed change,easy operate.
4)Optional universal handlebar.
♦Zhongshen power,easy start.
♦Oil filter,long life time of the engine.
Main Technical Parameter:
| Engine Type |
|
single cylinder,vertical shaft,4 stroke,air cooled |
|
Max Power Output HP(kw)/rpm |
|
8(4.5)/3600 |
| Engine Model |
|
VP200 |
|
Fuel Consumption (L/acre) |
|
1.1~1.4 |
| Transmission |
|
All gear driving |
|
Efficiency(acre /h) |
|
1.5-2.0 |
| Gear Shifting |
|
Stepless speed |
|
Fuel Tank capacity (L) |
|
2.5 |
| Starting |
|
Recoil start |
|
Displacement (cc) |
|
196 |
| Main Function |
|
Ditching,ridging,earth up |
|
Ditching Depth(mm) |
|
100~200 |
| Net weight (KG) |
|
60 |
|
Ridging height(mm) |
|
180 |
| Overall dimension(mm) |
|
1500*500*800(L*W*H) |
|
Working width(mm) |
|
250 |
