Operating indicators |
|
Visual |
1 LED (red/green/orange) |
Non-visual |
Buzzer |
Operating keys |
|
Entry options |
1 scan key |
Communication |
|
RS232 |
DB9 F connector with external power supply |
Keyboard Wedge |
MiniDIN6 F/M connector |
USB |
Ver. 1.1, HID, USB-A connector |
Power |
|
Voltage requirement |
5V ± 10% (Keyboard Wedge and USB), 6V (min. 4.5, max. 6.6V) (RS232) |
Barcode scanner Optics |
|
Light source |
630 nm red LED |
Scan method |
CCD linear Sensor 2500 pixels |
Scan rate |
200 scans/sec |
Trigger mode |
Manual, auto-trigger |
Reading pitch angle |
-35 to 0°, 0 to +35° |
Reading skew angle |
-70 to -20°, 20 to +70° |
Reading tilt angle |
-20 to 0°, 0 to +20° |
Curvature |
R>15 mm (EAN8), R>20 mm (EAN13) |
Min. resolution at PCS 0.9 |
0.125 mm / 5 mil |
Depth of field |
0 - 15 mm / 0 - 0.59 in, at PCS 0.9, Code 39 |
Supported Symbologies |
|
Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11,
Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 Databar (RSS), IATA,
Industrial 2of5, Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5,
MSI/Plessey, S-Code, Telepen, Tri-Optic,UK/Plessey |
Postal code |
Chinese Post, Korean Postal Authority code |
Durability |
|
Temperature in operation |
0 to 50 °C / 32 to 122 °F |
Temperature in storage |
-20 to 60 °C / -14 to 140 °F |
Humidity in operation |
5 - 95% (non-condensing) |
Humidity in storage |
5 - 95% (non-condensing) |
Ambient light immunity |
Fluorescent 10,000 lx max, Incandescent 10,000 lx max |
Drop test |
1.5 m / 5 ft drop onto concrete surface |
Vibration test |
10 - 100 Hz with 2G for 1 hour |
Protection rate |
IP 42 |
Physical |
|
Dimensions (w x h x d) |
53 x 75 x 150 mm / 2.09 x 2.95 x 5.91 in |
Weight body |
Ca. 90 g / 3.2 oz (excl. cable) |
Case |
ABS, Black or White |
Regulatory & Safety |
|
Product compliance |
CE, FCC, VCCI, RoHS |
