Option model
|
Standard
|
with voltage and frequency converter
|
Order number
|
9020-0379
|
9020-0357
|
Data
|
|
|
Serie
|
MKF
|
MKF
|
Performance Data Temperature
|
|
|
Average cooling down time according to IEC 60068-3-5 [K/min]
|
4.5
|
4.5
|
Average heating-up rate according to IEC 60068-3-5 [K/min]
|
5.5
|
5.5
|
Cooling down time from 180 °C to -40 °C [min]
|
100
|
100
|
Max. heat compensation at 25 °C [W]
|
2100
|
2100
|
Temperature fluctuation depending on setpoint [± K]
|
0.1…0.6
|
0.1…0.6
|
Temperature range (max. 24 °C unter Umgebungstemperatur) [°C]
|
-40…180
|
-40…180
|
Temperature variation depending on setpoint [± K]
|
0.1…1.3
|
0.1…1.3
|
Performance Data Climate
|
|
|
Dew point temperature range [°C]
|
5…94
|
5…94
|
Humidity fluctuation depending on setpoint
|
≤2,5 ± % RH
|
≤2,5 ± % RH
|
Humidity range [% RH]
|
10…98
|
10…98
|
Temperature fluctuation depending on setpoint [± K]
|
0.1…1.3
|
0.1…1.3
|
Temperature range (max. 24 °C unter Umgebungstemperatur) [°C]
|
10…95
|
10…95
|
Electrical data
|
|
|
Nominal power [kW]
|
4.8
|
4.8
|
Phase (Nominal voltage)
|
3~
|
3~
|
Power frequency [Hz]
|
50
|
60
|
Rated Voltage [V]
|
400
|
480
|
Unit fuse [A]
|
16
|
16
|
Doors
|
|
|
Unit doors
|
1
|
1
|
Housing dimensions not incl. fittings and connections
|
|
|
Depth net [mm]
|
865
|
865
|
Height net [mm]
|
1725
|
1725
|
Width net [mm]
|
980
|
980
|
Internal Dimensions
|
|
|
Depth [mm]
|
400
|
400
|
Height [mm]
|
480
|
480
|
Width [mm]
|
600
|
600
|
Measures
|
|
|
Interior volume [L]
|
115
|
115
|
Load per rack [kg]
|
30
|
30
|
Net weight of the unit (empty) [kg]
|
280
|
214
|
Permitted load [kg]
|
60
|
60
|
Viewing window height [mm]
|
222
|
222
|
Viewing window width [mm]
|
288
|
288
|
Wall clearance back [mm]
|
300
|
300
|
Wall clearance sidewise [mm]
|
200
|
200
|
Environment-specific data
|
|
|
Sound-pressure level [dB(A)]
|
62
|
67
|
Fixtures
|
|
|
Number of shelves (std./max.)
|
1/4
|
1/4
|
