CPU
|
PXA320 624MHz
|
OS
|
Microsoft® Windows Embedded CE 6.0 R2 · English Version
|
Memory
|
RAM
|
128MB
|
F-ROM
|
128MB
|
Autofocus CMOS Imager
|
Resolution
|
1D: 0,127 mm · 2D: 0,127 mm (Stacked) · 0,169 mm (Matrix)
|
Readable Distance
|
New All-Range technology*
|
Readable codes
|
1D
|
GS1 DataBar Omnidirectional (RSS-14), GS1 DataBar (RSS) Limited, GS1 DataBar (RSS) Expanded, GS1-128 (UCC/EAN128),Code128, Code93, Code39, Code11, EAN, UPC A/E, Codabar (NW7), ITF, MSI (Plessey), IATA, ISBTGS1
|
Stacked
|
GS1 DataBar (RSS-14) Stacked, GS1 DataBar (RSS-14) Stacked Omnidirectional, GS1 DataBar (RSS) Expanded Stacked, PDF417, Micro PDF, Composite, Codablock F, Code 32
|
Matrix
|
Aztec, DataMatrix, Maxicode, QR Code
|
Display
|
CASIO-Super-LCD
|
Transflective TFT, Color-LCD with touch panel
|
Size
|
8,89 cm, resolution: 240x320 QVGA, 65.536 colors
|
Background lighting
|
LED technology
|
Input
|
Keyboard light
|
34 keys, 3 scanner keys (center, left & right), 12 function keys with colored F1-F3 keys (with dual function = 24 function keys)
|
Background light
|
LED technology
|
Digital camera
|
Resolution
|
2 mega pixel CMOS
|
Focus
|
autofocus
|
Other functions
|
LED flash
|
Interfaces
|
Wireless LAN
|
IEEE802.11b (Max.11 Mbps), IEEE802.11g (Max.54 Mbps)
|
Bluetooth
|
Bluetooth® Version 2.0 + EDR
|
SD-Slot
|
microSD (SDHC)
|
Infrared
|
IrDA 1.3 (max. 4 Mbps)
|
Seriel
|
USB (Host / Client, only Cradle)
|
Audio
|
Buzzer, Speaker (mono), Microphone (mono)
|
Power supply
|
Battery
|
Lithium-ion battery: 7.4V / 2000mAh: about 18 hours
|
Back-up-battery
|
Lithium battery (rechargeable)
|
Dimensions
|
Aprox. 87 × 242 × 46 mm (L x B x H)
|
Weigth
|
about 560 g
|
Durability
|
Water / Splah proof
|
IP67
|
Drop Durability
|
1.8m
|
Operating Temperature
|
-20º C to +50º C
|
