Model
|
ILS-3NM-
25W
|
ILS-3NM-
30W
|
ILS-3NM-
55W
|
ILS-3NM-
60W
|
ILS-3NM-
80W
|
ILS-3NM-
100W
|
|
Laser Source
|
25W air-cooled
CO2 laser
|
30W air-cooled
CO2 laser
|
55W air-cooled CO2 laser
|
60W air-cooled CO2 laser
|
80W air-cooled CO2 laser
|
100W air-cooled
CO2 laser
|
|
Max. Speed
|
1524 mm/sec ( 60 inch/sec)
|
|
Resolution
|
1000,500,333,250,200,167DPI
|
|
Working Area
|
660(L) x 495(W)mm (25.98' x 19.48'inch)
|
|
Z-axis Moving
|
Adjustable distance up to 210mm
|
|
Max. Working Size
|
640 (L) x (W) x 170 (H) mm
|
|
Memory Buffer
|
Standard 64MB, stores up to 99 files with all settings
|
|
Computer Interface
|
Parallel port, Ethernet Port
|
|
Application Software
|
Windows compatible CAD, or graphics software
|
|
Operation Mode
|
Set up by driver, or operated by LCD control panel
|
|
Power
|
110/220VAC, 50-60Hz
|
|
Dimension
|
970 ( L ) x 865 ( W ) x990 ( H ) mm
|
|
Regulatory
|
CDRH Class 1, CEERTIFICATE
|
|
Cooling
|
Air-cooled, ambient temperature operational range: 15
|
