Name: Thiết bị dò dây và cáp điện Sonel LKZ-710
SKU: LKZ-710
Price: 2000000000 VND
Availability: InStock

Thông số kỹ thuật

Bảo hành	12 tháng

Đặc điểm nổi bật

- Hãng sản xuất: Sonel - Model: LKZ-710 - Xuất xứ: Ba Lan Wire tracer LKZ-710 is designed for detecting conductors in various environments (concrete, brick, wood) being under voltage, without the need to disconnect any devices from tested network.

- Hãng sản xuất: Sonel

- Model: LKZ-710

- Xuất xứ: Ba Lan

Wire tracer LKZ-710 is designed for detecting conductors in various environments (concrete, brick, wood) being under voltage, without the need to disconnect any devices from tested network.

LKZ-710 Technical Specifications

Detection of wires (live or using external power source):
- detecting of wires in ceilings, walls and floors,
- locating power points and switches in buildings,
- locating short circuits between leads (using external power source),
- tracing wires in metal ducts.
Identification of fuses on the distribution board.
Tracing conductive water and heating pipelines (using external power source).
Non-contact detection of live wires.
Signaling of transmitter and receiver opeartion by LED and sound.
- indication of signal level on dotted light line.
Features:
- operation in wide range of rated voltage, 12V DC (24V AC)...250V,
- two modes of transmitter amplification,
- adjustment of receiver sensitivity level,
- modes of wire tracer operation - current (detection of magnetic field),
- transmitter powered from tested installation.
