Bộ vi xử lý: |
Intel® Atom Z530 1.6GHz |
Hệ điều hành: |
Microsoft® Windows® CE 6.0, Microsoft® Windows® 7 Pro, Microsoft® Windows® Embedded Standard 7 (WES 7), Microsoft® Windows® Embedded Standard (WES 2009) |
Bộ nhớ: |
CE 6.0: 1GB, Windows 7 Pro, WES 7 & WES 2009: 2GB, DDR2 SDRAM |
Phần mềm hệ thống: |
CE 6.0: Microsoft® Internet Explorer 6, Microsoft® on-screen keyboard, DCWedge barcode wedge
Windows 7 Pro & WES 7: Microsoft® Internet Explorer 10, Freefloat Key on-screen keyboard, Freefloat Link wedge
WES 2009: Microsoft® Internet Explorer 8, Microsoft® on-screen keyboard, Freefloat Link wedge |
Phần mềm tuỳ chọn: |
CE 6.0: RFTerm TE, Naurtech CETerm & Industrial Browser, and Stay-Linked Terminal Emulators, Wavelink Avalanche & eXpressConfig network management
Windows 7 Pro, WES 7 & WES 2009: RFTerm TE, Freefloat Access TE Optional Remote Mastermind (ReM) remote device management |
Dung lượng lưu trữ: |
CE 6.0: 1GB
Windows 7 Pro: 32GB, optional 4GB industrial SD secondary SSD
WES 7: 16GB, optional 4GB industrial SD secondary SSD
WES 2009: 4GB, 8GB |
Xử lý đồ hoạ: |
Intel® GMA 500 |
Màn hình: |
9.7˝ (246 mm) XGA (1024x768) LED backlit display, 400 NIT, Optional screen blanking |
Màn hình cảm ứng: |
Industrial touch panel with resistive touch and support for finger touch and stylus |
Bàn phím: |
Five programmable multi-function keys |
Âm thanh: |
Audio for headset, Integrated stereo speakers w/ adjustable volume control, Integrated microphone |
Power Supply & UPS: |
10 to 60 VDC isolated, Optional external converters for AC (90-240VAC) & extended range DC (60-150 VDC); Integrated Li-ION maintenance UPS with 30-min life at -20°C standard |
Cổng kết nối: |
1x USB 2.0 powered host port, 1x USB 1.1 client port, 2x powered RS-232 COM ports, 1x CAN-bus port, 1x Headset port, DC power input & ignition control input, RF Antenna ports for WiFi (2), WWAN (1) & GPS (1) |
Mở rộng lưu trữ: |
User installable expansion slot supports 1GB and 4GB SD card |
WWAN |
Optional software definable (data only) 3.75G radio with five-band UMTS/HSPA+ (800/850/900/1900/2100MHz), quadband GSM/GPRS/EDGE (850/900/1800/1900MHz) and dual-band EV-DO/CDMA (800/1900) |
WLAN: |
Microsoft® Windows® CE 6.0: 802.11 a/b/g
Windows 7 Pro, WES 7 & WES 2009: 802.11 a/b/g/n
Wi-Fi™ – certified, CCX certified for data |
WLAN Security: |
Authentication: Support for a full range of 802.1X (EAP) types, including EAP-TLS, PEAP-MSCHAPv2, PEAPGTC, LEAP, and EAP-FAST Encryption: Support for Static, pre-shared, and dynamic encryption keys, 40-bit and 128-bit keys, WEP, WPA (TKIP), and WPA2 (AES) Encryption Methods |
WLAN Antennas: |
Dual internal antennas, dual external remote and direct connect antenna accessories |
WPAN: |
Bluetooth® 2.0+EDR standard, internal antenna |
GPS: |
Integrated Assisted GPS (A-GPS) with fast position acquisition and low power consumption. Included with WWAN radio |
Môi trường phát triển: |
Honeywell SDK available for Windows® CE 6.0; Standard Windows® SDK for Windows 7 Pro, WES 7, WES 2009 |
